GSM Repeater 4G 3G 2G Cellular Signal Booster Mobile Signal Repeater

Product Description:

Mobile Signal Repeater is a selective band repeater that provides reliable connection over a wide range of environments. It features a noise figure of ≤5dB, an operation temperature of -25℃ to +55℃, an EVM of ≤8, and a gain of 65-70dB. In addition, it is equipped with a N-K connector type for secure and efficient connection. With its high performance, it is the perfect choice for improving wireless signal coverage in any area.

The Mobile Signal Repeater is designed for improving wireless signal reception in public areas, commercial buildings, or any other areas where wireless signal coverage is weak. It boasts superior band selective repeater technology that can effectively eliminate interference from other signals, allowing the user to experience the best in wireless connection quality. This makes it an ideal solution for providing reliable signal coverage no matter the environmental conditions.

With its superior performance and reliable connection, the Mobile Signal Repeater is the perfect choice for improving wireless signal coverage. It is designed to provide a reliable signal over a wide range of environments, and it is capable of eliminating interference from other signals. This makes it the perfect solution for providing reliable signal coverage no matter the environmental conditions.

Features:

FrameAnt presents the GX-5 Three-Way Network Booster to optimize coverage of any three mobile networks simultaneously. With its LCD display, you can quickly view signal strength of inputs and outputs. The advanced isolation detection, auto gain control and auto level control enables maximum gain to strengthen the signal.

This booster is fully adjustable, permitting users to choose bandwidth between 0.2 to 20MHz. It is also highly flexible, as you can move the center frequency and select bandwidth of any mobile signal. The installation process is easy, with the built-in short LCD screen guiding you through the process with full smart support.

The GX-5 Three-Way Network Booster is also equipped with wifi control and monitoring capabilities, which allow you to manage the coverage of your booster and check performance levels quickly and conveniently.

Technical Parameters:

The frequency range of the device is 900MHz, with Uplink 880-915MHz and Downlink 925-960MHz, and the bandwidth is 35 MHz, which supports 2 sub-bands from 0.2 to 20 MHz adjusted. The gain for Uplink is 65dB and Dropink is 70dB with output power for Uplink 17+3dBm and Downlink 20+3dBm, and 31dB is the automatic gain control with 31dB@ 1dB/Step for MGC. The spurious emission is 9 kHz-150 kHz/1kHz, ≤-36dBm; 150 kHz- 30 MHz/10kHz, ≤-36dBm; 30 MHz-1 GHz/100kHz, ≤-36dBm; 1 GHz-12.75 GHz/1MHz,; ≤-30dBm, ACPR fully comply with 3GPP 36.106, and unwanted emissions fully comply with 3GPP 36.106, too. Out of band gain for 2100MHz is 1MHz≤ f_offset <5MHz, UL ≤ 30dB; DL ≤ 30dB, EVM ≤ 8, VSWR ≤ 2, Ripple ≤6dB, Noise Figure ≤ 5dB, Delay ≤ 3μs, I/O Impedance 50Ohm, with N-Type connector (female) for customers' choice. Remote and Local Control are Cloud WEB platform by SIM card and WIFI/ Type-C port, respectively. Bandwidth adjustment could only be done by Type-C port. Operating temperature can range from -25°C to +55°C, and the surrounding environment is IP43. It also has a maximum power consumption of 75W and weighs no more than 3kg, with a size of 234x230x52 (mm).

Applications:

ATNJ DS-EGSM Mobile Signal Repeater is a digital band selective repeater, designed to receive and amplify mobile phone signals in areas with weak signals. With its CE, RoHS and CCC certifications, this signal booster is safe and reliable to use. The minimum order quantity required is 5 pieces and the price ranges from $280 to $300. The product has an operation temperature range of -25℃ to +55℃ and uplink and downlink frequency ranges of 880-915MHz and 925-960MHz respectively. It comes with a professional EVM of ≤8 and a neutral standard package for delivery. The delivery time is usually 5-10 days and the payment terms include T/T, Paypal and Western Union. The supply ability of this product is 10000 pieces.

Customization:

Support and Services:

Technical Support and Service for Mobile Signal Repeater

We provide technical support and service for Mobile Signal Repeater. Our team of experienced engineers and technicians are available to answer any questions you may have about installation, maintenance, and troubleshooting.

We provide installation instructions, troubleshooting tips, and software updates and upgrades to ensure your Mobile Signal Repeater is always working optimally. We also provide customer support and technical assistance by phone, email, and online chat.

Please contact us if you require any additional assistance. We are more than happy to help you get the most out of your Mobile Signal Repeater.
