Product Details:
|
| Frequency Range: | Band3 1800MHz+Band N77 Customized 3300---4200MHz | Gain: | 70dB,UL Gp≥68 DL Gp≥70, Uplink Gp≥68dB Downlink Gp≥68dB, |
|---|---|---|---|
| Output Power: | 20dBm | AGC Intelligent Function: | Done,31dB @ 1dB/ Step |
| ALC Intelligent Function: | Done | MGC: | Done |
| RF Connect Type: | SMA/Female Connector | Weight: | 1.85kg |
| Packing Size: | 54x19x16cm | Trademark: | ATNJ |
| Origin: | Shenzhen,CN | ||
| High Light: | 1800MHz 5G Cell Repeater,15W Mobile Signal Booster 5G,15W 5G Cell Repeater |
||
Dual Band 5G Signal Booster 1800MHz + Customized 3300 - 4200MHz Mobile Signal Repeater
Selling Point
. Support the network extension coverage of NSA and SA networking mode at the same time
. MIMO dual channel input and output to improve system capacity and energy efficiency
. Isolation detection of donor and retransmission antenna
. Large AGC range
. High speed digital ALC
. Output power indication
. Automatic Dormancy
. When the equipment is self-excited, it will turn off automatically
. Unique equipment uplink squelch function, which does not interfere with the base station
. Automatic balance of uplink and downlink gain
. Small size, light weight, beautiful appearance, high gain and low power consumption
. Different output power levels to meet different coverage requirements
. Low noise amplification of equipment to improve voice quality and reduce dropped calls
. Convenient installation and opening
Technical Specifications
|
LTE 1800 Performance Characteristics |
|||
|
|
Uplink |
Downlink |
Remark |
|
Frequency range |
1710MHz-1785 MHz |
1805 MHz-1880 MHz |
|
|
Bandwidth |
75 MHz |
75 MHz |
|
|
Output power |
17±2dBm |
17±2dBm |
|
|
Device gain |
60±3dB |
65±3dB |
|
|
ALC/AGC Range |
≥30dB |
≥30dB |
|
|
Noise |
≤9dB |
≤9dB |
|
|
Ripple in band |
≤8dB |
≤8dB |
|
|
VSWR |
≤2.0dBm |
≤2.0dBm |
|
|
ACLR(dBc) |
≤-36 |
≤-36 |
|
|
Time delay |
≤3.0μs |
≤3.0μs |
|
|
Spurious emission |
9kHz～150kHz |
≤-36dBm @1kHz |
|
|
150kHz～30MHz |
≤-36dBm @10kHz |
|
|
|
30MHz～1GHz |
≤-36dBm @100kHz |
|
|
|
1GHz～12.75GHz |
≤-30dBm @1MHz |
|
|
|
EVM |
≤3.5% |
≤3.5% |
|
|
TDD-NR 3300---4200 Performance Characteristics |
|||
|
|
Uplink |
Downlink |
|
|
Frequency range |
3300MHz-4200MHz或3300MHz-4200MHz |
|
|
|
Bandwidth |
100 MHz |
|
|
|
Output power |
17±2dBm |
17±2dBm |
|
|
Device gain |
60±3dB |
60±3dB |
|
|
ALC/AGC Range |
≥30dB |
≥30dB |
|
|
Noise |
≤9dB |
≤9dB |
|
|
Ripple in band |
≤5dB |
≤5dB |
|
|
VSWR |
≤2.0dBm |
≤2.0dBm |
|
|
ACLR(dBc) |
≤-36 |
≤-36 |
|
|
Time delay |
≤3.0μs |
≤3.0μs |
|
|
Spurious emission |
9kHz～150kHz |
≤-36dBm @1kHz |
|
|
150kHz～30MHz |
≤-36dBm @10kHz |
|
|
|
30MHz～1GHz |
≤-36dBm @100kHz |
|
|
|
1GHz～12.75GHz |
≤-30dBm @1MHz |
|
|
|
256QAM EVM |
≤3.5% |
≤3.5% |
|
|
Performance Characteristics |
|||
|
Working voltage |
DC 5.0V |
|
|
|
Working current |
≤3.0A |
|
|
|
Power adapter input voltage |
AC 100～240V,50/60Hz |
|
|
|
Power comsumption |
≤15W |
|
|
|
Enviroment temperature |
-25℃～+55℃ |
|
|
|
relative humidity |
≤85% |
|
|
|
Device connection type |
SMA-J |
|
|
|
Power port |
KLD-35-13 |
|
|
|
Device size |
205×170×38mm |
|
|
|
Weight |
≤1Kg |
|
|
