Product Description:
With a bandwidth range of 0.2MHz to 20MHz adjustment (upon request), this band-selective signal booster can be customized to fit the specific needs of your location. The device measures 234*230*52mm, making it compact and easy to install in a variety of settings. The output power of this repeater can reach up to 20 dBm, providing a strong and reliable signal boost to your 3G network.
In addition to its powerful signal-boosting capabilities, this 4G Signal Repeater comes equipped with a WIFI/Type-C port, allowing for easy and convenient connectivity to a variety of devices. Whether you're using this device at home, in the office, or on the go, the Band Selective Repeater is a versatile and reliable choice for enhancing your 3G network.
Features:
- Intelligent to guide the installation with LCD.
- Real-time displays the signal strength.
- Automatic dormancy when no user makes the call.
- Automatic alarm when installation mistake and provide the appropriate solution.
- Automatic adjust the system gain to avoid the repeater self-excitation.
- Initiative reminding when the device was damaged.
- WIFIMonitor+Control(Customized), NMS(network management system), Function Optional.
Technical Parameters:
|
|
|
Frequency Range (Customers to Choose)
|
2100MHz UL: 1920-1980MHz; DL: 2110-2170MHz
|
|
Frequency Bandwidth
|
60MHz; Supports 1 Sub-bands From 0.2 To 20MHz Bandwidth Adjusted
|
|
Gain
|
UL: 65dB DL: 70dB
|
|
Automatic gain control (Step Attenuation)
|
Automatic gain control (Step Attenuation)
|
|
Auto Gain Control
|
20dB Min.
|
|
Output Power(Customers to Choose)
|
UL:15dBm DL:≥17dBm |
|
|
≤ -15dBm/30kHz
|
|
9kHz~1GHz: ≤ -36dBm/30kHz
|
|
1GHz~12.75GHz: ≤ -30dBm/30kHz
|
|
In-band Ripple
|
≤ 3dB
|
|
Inter-Modulation Attenuation ACPR
|
≤ -40dBc / 30kHz (measured under rated output power)
|
|
VSWR
|
<=2
|
|
I/O Impedance
|
50 Ω
|
|
Noise Figure
|
≤ 5dB
|
|
RF Connector(Customers to Choose)
|
N (Female)
|
|
Operating Temperature
|
Operation: - 10°C ~ + 55°C / Storage: -20°C ~ +60°C
|
|
Power Supply
|
AC 110~220V±20%, 50/60Hz(AC 220V/ DC5V/2A power adapter)
|
|
Weight
|
≤5 kg(Net)
|
|
Alarm Monitoring System
|
Alarm for uplink self-oscillation
|
|
Indication LED
|
Power supply
|
Applications:
Some of the product application occasions and scenarios include but are not limited to:
- 1. Homes - The Band Selective Repeater product is ideal for use in homes with weak or unstable signals. It can amplify signals from various networks, ensuring reliable connectivity for different devices.
- 2. Offices - Offices with large areas may experience weak signals, which can be detrimental to business operations. The Band Selective Repeater product can help solve this problem by boosting signals, ensuring seamless connectivity for all employees.
- 3. Hotels - Guests staying in hotels expect reliable connectivity for their devices. The Band Selective Repeater product can provide hotels with a cost-effective solution for boosting signals, ensuring guest satisfaction.
- 4. Public areas - Public areas such as airports, shopping malls, and hospitals require reliable connectivity for their visitors. The Band Selective Repeater product can help provide seamless connectivity by boosting signals from various networks.
The Band Selective Repeater product is equipped with WIFI/Type-C port, allowing for easy connectivity to different devices. Its compact size, energy efficiency, and user-friendly interface make it an ideal solution for various signal boosting needs.
Support and Services:
The Band Selective Repeater product comes with the following technical support and services:
- 24/7 technical support via phone and email
- On-site installation and commissioning
- Training for end-users and technicians
- Regular software and firmware updates
- Warranty and repair services
Our team of experienced technicians and support staff are dedicated to ensuring the optimal performance and reliability of your Band Selective Repeater.
Shipping:
The Band Selective Repeater is shipped using standard ground shipping. Shipping times may vary depending on the destination. The product will be shipped within 72 hours of receipt of payment.
