Home /Products/Band Selective Repeater/Digital Selective Band8 900MHz Mobile Signal Booster 2G Signal Repeater GSM

Digital Selective Band8 900MHz Mobile Signal Booster 2G Signal Repeater GSM

5Pcs
MOQ
＄200-240
Price
Digital Selective Band8 900MHz Mobile Signal Booster 2G Signal Repeater GSM
Features Gallery Product Description Chat Now
Features
Specifications
Frequency Range: UL: 890-915MHz; DL: 935-960MHz
Bandwidth: 25MHz; Supports 1 Sub-bands From 0.2 To 25MHz Bandwidth Adjusted For Each Band
Local Control: WIFI/ Type-C Port, Bandwidth Adjustment Could Be Done By Type-C Only
Dimensions: 234*230*52 (mm)
Gain: 70±3dB
Output Power: 20±2dBm
Input/Output Impedance: 50Ω
Noise Figure: ≤8dB
Vswr: ≤1.5
Weight: ≤5kg
Highlight:

2G Band Selective Repeater

,

GSM Band Selective Repeater

,

900MHz Band Selective Repeater
Basic Infomation
Place of Origin: Guangdong China
Brand Name: ATNJ
Certification: CE ROHS CCC ISO
Model Number: AS-140-135-G
Document: 140-135-900MHz Digital sele...nd.pdf
Payment & Shipping Terms
Packaging Details: Neutral standard package 44x44x30cm
Delivery Time: 5--8 working days
Payment Terms: T/T,Paypal,Western Union，Alibaba insurance payment
Product Description

Product Description:

ATNJ Digital RF repeater with industrial design, Special for mobile provider need, combines multi mobile network signals together and improves the mobile voice and data communication, aiming to provide a more cost-effective solution for signal. ATNJ Digital RF repeater is easy to install and maintain,which could help signal providers get fast solution.



Selling point:



①Intelligent to guide the installation with LCD

②Real time display the signal strength.
Automatic dormancy when no user make the calling .
③Automatic alarm when installation mistake and provide the according solution .
④Automatic adjust the system gain to avoid the repeater self-excitation .
⑤Initiative reminding when the device was damaged .
⑥Supports from 0.2 to 35MHz bandwidth adjusted(Customized) ,Supports 5G bandwidth,40MHz,50MHz,60MHz,70MHz,80MHz,90MHz,100MHz(Frequency Bandwidth Customized) .
⑦WIFIMonitor+Control(Customized),NMS(network management system),Function Optional .

Digital Selective Band8 900MHz Mobile Signal Booster 2G Signal Repeater GSM 0



Technical Parameters:

SPECIFICATIONS
Parameters
Frequency Range (Customers to Choose)
900MHz UL: 890-915MHz; DL: 935-960MHz
Frequency Bandwidth
25MHz; Supports 1 Sub-bands From 0.2 To 25MHz Bandwidth Adjusted for each band
Gain
UL:65dB DL:70dB
Automatic gain control (Step Attenuation)
Automatic gain control (Step Attenuation)
Auto Gain Control
20dB Min.
Output Power(Customers to Choose)



UL:15dBm DL:≥17dBm

Spurious Emission
≤ -15dBm/30kHz
9kHz~1GHz: ≤ -36dBm/30kHz
1GHz~12.75GHz: ≤ -30dBm/30kHz
In-band Ripple
≤ 3dB
Inter-Modulation Attenuation ACPR
≤ -40dBc / 30kHz (measured under rated output power)
VSWR
<=2
I/O Impedance
50 Ω
Noise Figure
≤ 5dB
RF Connector(Customers to Choose)
N (Female)
Operating Temperature
Operation: - 10°C ~ + 55°C / Storage: -20°C ~ +60°C
Power Supply
AC 110~220V±20%, 50/60Hz(AC 220V/ DC5V/2A power adapter)
Weight
≤0.8 kg(Net)
Alarm Monitoring System
Alarm for uplink self-oscillation
Indication LED
Power supply



Digital Selective Band8 900MHz Mobile Signal Booster 2G Signal Repeater GSM 1

Digital Selective Band8 900MHz Mobile Signal Booster 2G Signal Repeater GSM 2

Digital Selective Band8 900MHz Mobile Signal Booster 2G Signal Repeater GSM 3

Digital Selective Band8 900MHz Mobile Signal Booster 2G Signal Repeater GSM 4

Digital Selective Band8 900MHz Mobile Signal Booster 2G Signal Repeater GSM 5



Applications:



  • Indoor: Hotels, Exhibition Centers, Basement, Parking Lots, Shopping Malls, Apartments..
  • Outdoor: Airport, Tunnel, Village, Mining Area, Court, Tourism Area..

Digital Selective Band8 900MHz Mobile Signal Booster 2G Signal Repeater GSM 6



ATNJ Strength & Service

Highly qualified communication technology Engineers. ATNJ brings together a team of engineers with more than ten years of working experience in communication industry, who are engaged in signal booster R&D, design, debugging, testing, and its pre-production to ensure it could comply with International Standards. For the sustainable development of the company, some young engineers are also employed. Because of their hard work, the ATNJ's products can be continuously updated and iterated.

Satisfactory after-sales service. ATNJ provides 3-year warranty for all the main signal repeater, and 3-month warranty for
accessories. Within the warranty period, ATNJ provides free repairment service, and customers only need to pay for the freight. In addition, within one month after the customer receives the product, ATNJ is responsible for all non-human damage faults.
Contact us and place order now, to have better signal, better life.
