Multi Band Repeater
>
Tri Band 850MHz 900MHz 2100MHz CDMA GSM UMTS Signal Booster Amplifier Repeater

Tri Band 850MHz 900MHz 2100MHz CDMA GSM UMTS Signal Booster Amplifier Repeater

Brand Name: ATNJ
Model Number: NT-CGW
MOQ: 1
Price: USD+210---240+kit
Packaging Details: Standard neutral packing,52x24x16cm(1 kit),
Payment Terms: T/T, Western Union,Paypal,Alibaba,Bank transfering.
Detail Information
Place of Origin:
China
Certification:
CE,ROHS,CCC,TUV,BV, ISO
850MHz Frequency Range:
825-835MHz; 870-880MHz
900MHz Frequency Range:
890-915MHz; 935-960MHz
2100MHz Frequency Range:
1920-1980MHz; 2110-2170MHz
Device Gain:
Uplink :60±3dB, Downlink: 65±3dB
Device Output Power:
Uplink :13±2dBm, Downlink:20±dBm
Color For Choice:
White, Black
Device RF Connect Type:
SMA/Female
Supply Ability:
1000+unit+per day.
High Light:

Tri Band Signal Booster Amplifier

,

850MHz Signal Booster Amplifier

,

GSM Multi Band Repeater

Product Description

850MHz 900MHz 2100MHz Tri Band Mobile Booster



CDMA GSM UMTS 2G 3Gnetwork Cell Phone Signal Repeater Amplifier




The 850/900/2100MHz Pico Repeater provides an affordable solution to solve the indoor signal coverage problems due to signal fading and attenuation caused by architecture obstacles. And its easy installation and maintenance can help carrier get fast return.
The repeater is working as a relay between the BTS and mobiles. It picks up the strongest signal from BTS via the Donor Antenna, linearly amplifies the signal and then retransmits it via the Indoor Signal Distribution System to the weak/blind coverage area. And the mobile signal is also amplified and retransmitted to the BTS via the opposite direction.







Specification:



SPECIFICATIONS
PARAMETERS
Frequency Range


CDMA 850MHz
825-835MHz/870-880MHz
GSM 900MHz
890-915MHz/935-960MHz

 WCDMA 2100MHz

1920-1980MHz/2110-2170MHz
Band Width


CDMA 850MHz
10MHz
GSM 900MHz
25MHz
WCDMA 2100MHz
60MHz
Gain
65±3dB
Automatic Gain Control
31dB
MGC (Step Attenuation)
31dB@ 1dB/Step
Output Power
20±2dBm
Spurious Emission
9 kHz -150 kHz/1kHz
≤-36dBm

150kHz-30MHz/10kHz
≤-36dBm

30 MHz-1GHz/100kHz
≤-36dBm

1GHz-12.75GHz/1MHz
≤-30dBm
ACPR
Uplink Fully comply with 3GPP 36.106

Downlink Fully comply with 3GPP 36.106
Unwanted emissions
Fully comply with 3GPP 36.106
VSWR
≤2
Ripple
CDMA 850MHz
≤6dB

GSM 900MHz
≤6dB

WCDMA 2100MHz
≤6dB
Noise Figure
≤7dB
Delay
≤1μs
I/O Impedance
50Q
RF Connector(Customers to Choose)
SMA-Type (Female)
Operating Temperature
-25°~+55°
Power Supply
DC 5V
Power consumption
≤75W
Environment Conditions
IP43
Humidity
≤90%
Weight
0.5kg
Size
205*165*45mm



Packaging & delivery

package size:
52X24X16 cm
weight:
4.000 kg



Selling Point


. Support the network extension coverage of NSA and SA networking mode at the same time
. MIMO dual channel input and output to improve systemobilescity and energy efficiency
. Isolation detection of donor and retransmission antenna
. Large AGC range
. High speed digital ALC
. Output power indication
. Automatic Dormancy
. When the equipment is self-excited, it will turn off automatically
. Unique equipment uplink squelch function, which does not interfere with the base station
. Automatic balance of uplink and downlink gain
. Small size, light weight, beautiful appearance, high gain and low power consumption
. Different output power levels to meet different coverage requirements
. Low noise amplification of equipment to improve voice quality and reduce dropped calls
. Convenient installation and opening



Item Descrption

Tri Band 850MHz 900MHz 2100MHz CDMA GSM UMTS Signal Booster Amplifier Repeater 0



Applications:

To expand signal coverage or fill signal blind area where signal is weak or unavailable.



Indoor: Hotels, exhibition centers, basements, shopping malls, offices, parking lots, …

Tri Band 850MHz 900MHz 2100MHz CDMA GSM UMTS Signal Booster Amplifier Repeater 1Tri Band 850MHz 900MHz 2100MHz CDMA GSM UMTS Signal Booster Amplifier Repeater 2



FAQ


1. How many mobiles can support a cell phone repeater at the same time?

The number of simultaneous subscribers is not limited. The key factor is not to move out of the area of coverage.

2. How do I know what cell phone repeater suits my country and mobile operator?
For your convenience, we have developed a special Search form. To find which cell phone repeaters are suitable for your country and operator just select your country and we will provide you with all possible options.


3: Is it easy to set up your items?
A: Yes. We have a user manual and support technical support 24/7.

4. What is your warranty time?
We promise a 3-year warranty for all products shipped from us. Man-made sabotage and natural factors are not within the scope of warranty.

5. Please feel free to contact us if any other questions.
