High Gain 80dB GSM Mobile Signal Repeater With ALC AGC Function

Product Details

Place of Origin: China

Brand Name: ATNJ

Certification: CE,ROHS,CCC,TUV,BV, ISO

Model Number: MS-G

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: USD+100---120+kit

Packaging Details: Standard neutral packing,52x21x16cm(1 kit), 6kits as 1 carton(53x49x42cm)

Delivery Time: 3-5 work days

Payment Terms: T/T, Western Union,Paypal,Alibaba,Bank transfering.

Supply Ability: 1000+unit+per day.

Get Best Price
Highlight:

80dB GSM Mobile Signal Repeater

,

AGC GSM Mobile Signal Repeater

,

ALC High Gain Signal Repeater

Frequency Range:
890-915MHz/935-960MHz
Gain:
80dB
AGC Intelligent Function:
Done,31dB @ 1dB/ Step
Output Power:
23-27dbm
RF Connect Type:
N/Female
Packing Size:
52x21x16cm
Lightning Protection::
With Lightning Protection
Products Type:
Hiboost Cell Phone Signal Booster, Gsm Signal Booster For 10km
Frequency Range:
890-915MHz/935-960MHz
Gain:
80dB
AGC Intelligent Function:
Done,31dB @ 1dB/ Step
Output Power:
23-27dbm
RF Connect Type:
N/Female
Packing Size:
52x21x16cm
Lightning Protection::
With Lightning Protection
Products Type:
Hiboost Cell Phone Signal Booster, Gsm Signal Booster For 10km
High Gain 80dB GSM Mobile Signal Repeater With ALC AGC Function

High Gain 80dB GSM Mobile Signal Repeater With ALC AGC Function



80dB Gain ALC MGC GSM Signal Booster With N Female RF Connect



Model No :AS-G
With ALC AGC Function
Can control gain automatically. Avoid base station interference

(Band 8) 900MHz -- Uplink frequency: 890-915MHz/Downlink frequency : 935-960MHz
Network support : 2G, Calling
Gain :70±2dB
Power Supply :AC110V~220V;DC+5V/2A
Connector Type: SMA-female connector.

Technical Specifications



Specifications

Parameters

Frequency Range (Customers to Choose)

Uplink

890-915MHz

Downlink

935-960MHz

Frequency Bandwidth (3dB Bandwidth)

30MHz

Gain

80dB

Automatic gain control (Step Attenuation)

31dB @ 1dB/ Step

Auto Gain Control

20dB Min.

Output Power(Customers to Choose)

27dBm

Spurious Emission

≤ -15dBm/30kHz

9kHz~1GHz: ≤ -36dBm/30kHz

1GHz~12.75GHz: ≤ -30dBm/30kHz

Inter-Modulation Attenuation ACPR

≤ -40dBc / 30kHz (measured under rated output power)

In-band Ripple

≤ 3dB

VSWR

<=2

I/O Impedance

50 Ω

Noise Figure

≤ 5dB

System Delay

≤ 5μs

RF Connector(Customers to Choose)

N(Female)

Operating Temperature

 - 10°C ~ + 55°C

Dimensions

165*130*40 (mm)

Further detail pls click here for downloading the products specification:

GSM 900MHz B011A Signal Repeater.pdf



Features:

1. Cost effective solution for weak signal zones, reduce drop/off calls.

2. Compact size, low power consumption,

3. easy installation, great cover.

4. Expansion and extending of the signal of base station.

5. Optimization of the quality of the signal and source

6. Cover about 500~3000m² without block or obstruct.

7. Support any cellular devices (voice & data )

8. Wide band signal booster, or customize selective band booster.



Product Description

High Gain 80dB GSM Mobile Signal Repeater With ALC AGC Function 0High Gain 80dB GSM Mobile Signal Repeater With ALC AGC Function 1

High Gain 80dB GSM Mobile Signal Repeater With ALC AGC Function 2High Gain 80dB GSM Mobile Signal Repeater With ALC AGC Function 3High Gain 80dB GSM Mobile Signal Repeater With ALC AGC Function 4High Gain 80dB GSM Mobile Signal Repeater With ALC AGC Function 5High Gain 80dB GSM Mobile Signal Repeater With ALC AGC Function 6High Gain 80dB GSM Mobile Signal Repeater With ALC AGC Function 7

High Gain 80dB GSM Mobile Signal Repeater With ALC AGC Function 8High Gain 80dB GSM Mobile Signal Repeater With ALC AGC Function 9

High Gain 80dB GSM Mobile Signal Repeater With ALC AGC Function 10



FAQ:


1. Are you trading company or manufacturer ? Could I use our own logo and label?

We are factory, with trading service. We provide OEM/OEM service.

2. Can I have a sample order? What is your MOQ?
Yes, we welcome sample order to test and check quality. MOQ is 1 for normal products.

3: Is it easy to set up your items?
A: Yes. We have a user manual and support technical support 24/7.

4. What is your warranty time?
We promise 3-year warranty for all products shipped from us. Man-made sabotage and natural factors are not within the scope of warranty.





5. What is our Certificates ?



We have CE, ROHS, CCC certificates .





Please feel free to contact us if any other questions.
