Product Details
Place of Origin: China
Brand Name: ATNJ
Certification: CE,ROHS，CCC，TUV,BV， ISO
Model Number: AS-MS-G
Document: AT003 2W 900MHz Powerful Si...er.pdf
Payment & Shipping Terms
Minimum Order Quantity: 5Pcs
Price: USD+230---250+kit
Packaging Details: Standard neutral packing,54x19x16cm(1 kit), 6kits as 1 carton(53x49x42cm)
Delivery Time: 3-5 work days
Payment Terms: T/T, Western Union,Paypal,Alibaba,Bank transfering.
Supply Ability: 1000+unit+per day.
Frequency Range: |
890-915MHz，935-960MHz |
Booster Gain: |
85dB |
Booster Power: |
27--30dBm |
Material: |
Zinc Alloy ,Plastic |
Support Network: |
2G 3G, Voice |
Products Type: |
Phone Signal Amplifier, Modeltrain Signal Ho |
Frequency Range: |
890-915MHz，935-960MHz |
Booster Gain: |
85dB |
Booster Power: |
27--30dBm |
Material: |
Zinc Alloy ,Plastic |
Support Network: |
2G 3G, Voice |
Products Type: |
Phone Signal Amplifier, Modeltrain Signal Ho |
2 Watt Gain 85dB GSM Mobile Signal Booster For 2G Voice Call Network
2 Watt GSM Mobile Signal Booster Repeater Amplifier for calling 2G voice
Model No :AS-MS-G
With ALC AGC Functionr
Can control gain automatically. Avoid base station interference
(Band 8) 900MHz -- Uplink frequency: 890-915MHz/Downlink frequency : 935-960MHz
Network support : 2G Voice
Gain :85±2dB
Output power : 2 watt .
Power Supply :AC110V～220V;DC+5V/2A .
Connector Type: N-F
Wide Range .
|
Single Band Repeater with AGC/MGC |
||||
|
Model |
AS-MS-G |
|||
|
Frenquecy Range |
UplinK:890~915MHz Downlink:935~960MHz |
|||
|
Working System |
Band8 GSM 900MHz |
|||
|
Gain |
85±2dB |
|||
|
Device Output Power |
27--30dBm |
|||
|
Bandwidth |
Wide Range |
|||
|
Ripple in Band |
≤4dB |
|||
|
Noise Figure @ Max.Gain |
≤6dB |
|||
|
V.S.W.R |
≤2dB |
|||
|
MTBF |
>50000Hours |
|||
|
Power Supply |
AC110V～220V;DC+5V/2A |
|||
|
Power Comsumption |
<20W |
|||
|
Impedance Matching |
50ohm |
|||
|
Mechanical Specification |
||||
|
RF Connector |
SMA/F |
|||
|
Cooling |
Heatsink Convection Cooling |
|||
|
Dimension |
170*130*26(mm) |
|||
|
Net Weight |
0.35KG |
|||
|
Installation Type |
Wall Installation or Desk |
|||
|
Environment Conditions |
IP40 |
|||
|
Origin |
Shenzhen |
|||
|
Operating Temperature |
-10°C~55°C |
|||
Further detail pls click here for downloading the products specification:
Selling Point
1. Intelligent to guide the installation with LCD
2. Real time display the signal strength.
3. Automatic dormancy when no user make the calling
4. Automatic alarm when installation mistake and provide the according solution
5. Automatic adjust the system gain to avoid the repeater self-excitation
6. Initiative reminding when the device was damaged.
FAQ:
1. Are you trading company or manufacturer ? Could I use our own logo and label?
We are factory, with trading service. We provide OEM/OEM service.
2. Can I have a sample order? What is your MOQ?
Yes, we welcome sample order to test and check quality. MOQ is 1 for normal products.
3. Is it easy to set up your items?
Yes. We have a user manual and support technical support 24/7.
4. Can this mobile signal repeater create a signal where there is no cell signal before?
The mobile signal repeater cannot produce a signal, only amplify a weak one.
5. Could I get a sample before bulk order?
Yes, we offer the sample for all models but charged.
