Dual Band Repeater
>
Dual Band 900MHz 2300MHz GSM LTE Signal Booster With LCD Display

Dual Band 900MHz 2300MHz GSM LTE Signal Booster With LCD Display

Brand Name: ATNJ
Model Number: JS-DB900/2300/P
MOQ: 1
Price: USD+120---140+kit
Packaging Details: Standard neutral packing,52x21x16cm(1 kit), 4kits as 1 carton(54x49x33cm)
Payment Terms: T/T, Western Union,Paypal,Alibaba,Bank transfering.
Detail Information
Place of Origin:
China
Certification:
CE,ROHS,CCC,TUV,BV, ISO
900MHz Frequency Range:
890-915MHz / 935-960MHz
2300MHz Frequency Range:
2300-2400MHz / 2300-2400MHz
Color:
Grey ,Customized
Warranty:
36 Months
Packing Size:
52x21x16cm
Products Type:
4G Signal Repeater, Mf8518 4g Signal Booster
Supply Ability:
1000+unit+per day.
High Light:

2300MHz GSM LTE Signal Booster

,

900MHz GSM LTE Signal Booster

,

2300MHz Dual Band Wireless Repeater

Product Description

Dual Band 900MHz 2300MHz GSM LTE Signal Booster With LCD Display



Cellular Signal Booster GSM LTE Dual band Repeater 2G 4G 900 / 2300MHz Amplifier



The advantages of this GSM LTE amplifier include:



LCD Display:

Even a non-technical person can easily install and use this signal booster. The display shows all important information and prompts: input and output signal strength, installation details, power, AGC (automatic gain control), etc.



Sleep Mode:

In the absence of incoming and outgoing calls and data transmission over the Internet, the LCD amplifier goes into sleep mode. This function helps to save energy.



Automatic Adjustment Of Operation:

GSM+4G LTE amplifier can adjust the system gain and signal level. All this helps to avoid self-excitation of the device. If a problem occurs, the device will turn off automatically.



Compact Size And High-tech Design:

The signal amplifier has a small size, light weight, advanced design and intelligent LCD display. It fits perfectly into any interior.



Technical Specifications

Specifications

Parameters

Frequency Range (Customers to Choose)

Uplink

890-915MHz, 2300-2400MHz

Downlink

935-960MHz, 2300-2400MHz

Frequency Bandwidth

25MHz/100MHz

Gain

≥70dB

Automatic gain control (Step Attenuation)

31dB @ 1dB/ Step

Auto Gain Control

20dB Min.

Output Power(Customers to Choose)

≥20dBm

Spurious Emission

≤ -15dBm/30kHz

9kHz~1GHz: ≤ -36dBm/30kHz

1GHz~12.75GHz: ≤ -30dBm/30kHz

Inter-Modulation Attenuation ACPR

≤ -40dBc / 30kHz (measured under rated output power)

In-band Ripple

≤ 3dB

VSWR

<=2

I/O Impedance

50 Ω

Noise Figure

≤ 5dB

System Delay

≤ 5μs

RF Connector(Customers to Choose)

SMA(Female)

Operating Temperature

Operation: - 10°C ~ + 55°C / Storage: -20°C ~ +60°C

Power Supply

AC 110~220V±20%, 50/60Hz(AC 220V/ DC5V/2A power adapter)

Dimensions

165*130*40 (mm)

Weight

≤0.8 kg(Net)

Alarm Monitoring System

Alarm for uplink self-oscillation

Indication LED

Power supply

Further detail pls click here for downloading the products specification:

900+2300MHz 006 mobile signal repeater.pdf



Product Description



Dual Band 900MHz 2300MHz GSM LTE Signal Booster With LCD Display 0

Dual Band 900MHz 2300MHz GSM LTE Signal Booster With LCD Display 1Dual Band 900MHz 2300MHz GSM LTE Signal Booster With LCD Display 2Dual Band 900MHz 2300MHz GSM LTE Signal Booster With LCD Display 3Dual Band 900MHz 2300MHz GSM LTE Signal Booster With LCD Display 4

Dual Band 900MHz 2300MHz GSM LTE Signal Booster With LCD Display 5Dual Band 900MHz 2300MHz GSM LTE Signal Booster With LCD Display 6Dual Band 900MHz 2300MHz GSM LTE Signal Booster With LCD Display 7Dual Band 900MHz 2300MHz GSM LTE Signal Booster With LCD Display 8

Dual Band 900MHz 2300MHz GSM LTE Signal Booster With LCD Display 9Dual Band 900MHz 2300MHz GSM LTE Signal Booster With LCD Display 10Dual Band 900MHz 2300MHz GSM LTE Signal Booster With LCD Display 11







FAQ:

1. Are you trading company or manufacturer ? Could I use our own logo and label?

We are factory, with trading service. We provide OEM/OEM service.

2. Can I have a sample order? What is your MOQ?
Yes, we welcome sample order to test and check quality. MOQ is 1 for normal products.

3. Is it easy to set up your items?
Yes. We have a user manual and support technical support 24/7.

4. What is your warranty time?
We promise 3-year warranty for all products shipped from us. Man-made sabotage and natural factors are not within the scope of warranty.

5. Please feel free to contact us if any other questions.
