Digital band selective repeater 900MHz cellphone signal booster GSM mobile signal repeater GSM Digital selective DAS
| 900MHz frequency range: | 880-915MHz; 925-960MHz | Bandwidth: | 35MHz; Supports From 0.2 To 20MHz Bandwidth Adjusted |
| Gain: | UL: 65dB; DL: 70dB | Output Power(Customers to Choose): | UL: 15dBm; DL: ≥17dBm |
| Dimensions: | 234*230*52mm | Power Supply: | AC 100-240V, 50/60Hz |
| Color: | Black , Customized | Warranty: | 3 Years |
| High Light: | 900MHz cellphone signal booster,GSM Digital selective amplifier,2G mobile signal repeater |
||
Product Description:
Features:
① Intelligent to guide the installation with LCD.
⑤ Automatic adjust the system gain to avoid the repeater self-excitation.
⑥ Initiative reminding when the device was damaged.
Technical Parameters:
| AS-140-135-G | 900 MHz | ||||||||||||
| Frequency Range | Uplink | 880-915MHz | |||||||||||
| Downlink | 925-960MHz | ||||||||||||
| Number of Sub-Bands | 1 Sub-Band | ||||||||||||
| Bandwidth | 35MHz, each Sub-Band support (0.2 - 20 MHz adjustable) | ||||||||||||
| Max Gain | Uplink | 65dBm | |||||||||||
| Downlink | 70dBm | ||||||||||||
| Manual Gain Control | 31 dB in step of 1 dB | ||||||||||||
| Automatic Gain Control | ≧ 20 dB | ||||||||||||
| Gain Flatness | ≦ ±2 dB (peak-to-peak) | ||||||||||||
| Max. Input Power Without Damage | 0 dBm | ||||||||||||
| Output Power | Uplink | 17 ±2dBm | |||||||||||
| Downlink | 20 ±2dBm | ||||||||||||
| Operating band unwanted emissions | Comply with 3GPP | ||||||||||||
| Spurious Emission | 9kHz~1GHz | ≦ -36dBm | |||||||||||
| 1GHz~12.75GHz | ≦ -30dBm | ||||||||||||
| ACPR | ±20MHz | Uplink≦-36dBc/Downlink≦-45dBc | |||||||||||
| ±40MHz | Uplink≦-45dBc/Downlink≦-50dBc | ||||||||||||
| EVM | ≦ 8 | ||||||||||||
| Frequecy Stability | ≦ ±0.01 ppm | ||||||||||||
| Noise Figure | ≦ 8 dB | ||||||||||||
| VSWR | ≦ 2 | ||||||||||||
| Group Delay | ≦ 3 μs | ||||||||||||
| RF Connector | N-Female | ||||||||||||
| Impedance | 50 Ω | ||||||||||||
| Power Supply | Input: AC 100~240 V; Output: DC 5 V/ 5 A | ||||||||||||
| Power Consumption | ≦ 75 W | ||||||||||||
| Dimensions | 234*230*52mm | ||||||||||||
| Weight | ≦ 5 Kg | ||||||||||||
| IP Rating | IP40 | ||||||||||||
| Operating Temperature | -25 ℃ to 55 ℃ | ||||||||||||
| Control & Monitoring |
Local | WIFI/Type-C port | |||||||||||
| Remote | Optional | ||||||||||||






A mobile phone signal repeater provides the ultimate solution in any area where cellular communications can not work well due to leak of signals. The repeater device features easy installation & operation, build-in indoor antenna and no interference.
It could also improve indoor electromagnetism environments, protract cellular battery life and reduce radiation of cellphones. A mobile phone repeater is ideal for house, home, office use.
The repeater makes the signal stronger in places with poor signal coverage such as:
1) Underground areas: basements, parking lots, tunnels;
2) Other places where cellular signal is shielded by metal or concrete walls: offices, supermarkets, cinemas, hotels;
3) Places distant from the BTS like private houses.
