800MHz Lte 4g Repeater Amplifiers Cellular Network Signal Booster 70dBi

Product Details

Place of Origin: China

Brand Name: ATNJ

Certification: CE,ROHS,CCC,TUV,BV, ISO

Model Number: AS-L800

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: USD+40---49+kit

Packaging Details: Standard neutral packing,54x19x16cm(1 kit), 6kits as 1 carton(53x49x42cm)

Delivery Time: 3-5 work days

Payment Terms: T/T, Western Union,Paypal,Alibaba,Bank transfering.

Supply Ability: 1000+unit+per day.

Get Best Price
Highlight:

BV 4G Signal Repeater

,

TUV Cellular Network Signal Booster

,

70dBi 4G Signal Repeater

Frequency Range:
791-821MHz/832-862MHz
Repeater Gain:
70dBi
Repeater Output:
17-20dBm
Color For Choice:
White,Blue,Customized
AGC Intelligent Function:
Done,31dB @ 1dB/ Step
RF Connect Type:
SMA/Female Connector
Power Supply:
AC 110~220V±20%, 50/60Hz(AC 220V/ DC5V/2A Power Adapter)
Inter-Modulation Attenuation ACPR:
≤ -40dBc / 30kHz (measured Under Rated Output Power)
Packing Size:
54x19x16cm
Products Type:
4G Repeater, Amplificador Celular
Frequency Range:
791-821MHz/832-862MHz
Repeater Gain:
70dBi
Repeater Output:
17-20dBm
Color For Choice:
White,Blue,Customized
AGC Intelligent Function:
Done,31dB @ 1dB/ Step
RF Connect Type:
SMA/Female Connector
Power Supply:
AC 110~220V±20%, 50/60Hz(AC 220V/ DC5V/2A Power Adapter)
Inter-Modulation Attenuation ACPR:
≤ -40dBc / 30kHz (measured Under Rated Output Power)
Packing Size:
54x19x16cm
Products Type:
4G Repeater, Amplificador Celular
800MHz Lte 4g Repeater Amplifiers Cellular Network Signal Booster 70dBi



800MHz LTE 4g repeater amplificateurs signal cellulaire network signal boaster





  A cell phone booster is a device that gathers the signal from the air, usually through an outdoor unit (such as an antenna), and “conveys” this signal to an indoor unit that is supposed to boost the signal. This conveying is done through a wired connection between the outdoor antenna and the indoor unit. The indoor cell phone booster, in turn, is provided with external power through a power outlet and has a complex circuitry that allows it to amplify the weak signal that has been received by the outdoor antenna. The indoor unit then sends the electrical signal to the indoor antenna that is directly connected to the unit, and the antenna converts the electrical signal to waves of the same frequency as were received by the outdoor unit. This, the frequency range of the waves does not change, and the cell phones do not notice any difference, except for a dramatic increase in the signal power that they are receiving.

  Thus, as we can see, cell phone signal boosters are devices that literally boost the cell phone signal that you are receiving. This is done through some complex circuitry that works through the use of external power and boosts the signal to usable levels.

Product Description
800MHz Lte 4g Repeater Amplifiers Cellular Network Signal Booster 70dBi 0
  • ATNJ Band20 800MHz mobile signal repeater

ATNJ RF repeater with industrial design, combines multi mobile network signals together and improves the mobile voice and data communication, aiming to provide a more cost-effective solution for signal. ATNJ RF repeater is easy to install and maintain, which could help signal providers get fast solution.
  • Selling Point

①Intelligent to guide the installation with LCD .②Real time display the signal strength .
Automatic dormancy when no user make the calling .
③Automatic alarm when installation mistake and provide the according solution .
④Automatic adjust the system gain to avoid the repeater self-excitation .
⑤Initiative reminding when the device was damaged .
⑥Supports from 0.2 to 20MHz bandwidth adjusted(Customized) .
Supports 5G bandwidth, 40MHz,50MHz,60MHz,70MHz,80MHz,90MHz,100MHz(Frequency Bandwidth Customized) .
⑦With WIFI Monitor+Control(Customized),NMS(network management system),Function Optional .
800MHz Lte 4g Repeater Amplifiers Cellular Network Signal Booster 70dBi 1
SPECIFICATIONS
PARAMETERS
Frequency Range
LTE 800MHz
791-821MHz/832-862MHz
Bandwidth
LTE 800MHz
30MHz
Gain
70dB
Automatic Gain Control
31dB
MGC (Step Attenuation)
20dB@ 1dB/Step
Output Power
17±3




Spurious Emission
9 kHz -150 kHz/1kHz
≤-36dBm
150 kHz - 30 MHz/10kHz
≤-36dBm
30 MHz - 1 GHz/100kHz
≤-36dBm
1 GHz- 12.75 GHz/1MHz
≤-30dBm
ACPR
Uplink Fully comply with 3GPP 36.106
Downlink Fully comply with 3GPP 36.106
Unwanted emissions
Fully comply with 3GPP 36.106
VSWR
≤2
Ripple
LTE800
≤3dB
Noise Figure
≤5dB
Delay
≤1μs
I/O Impedance
50Q
RF Connector(Customers to Choose)
SMA-Type (Female)
Operating Temperature
-25°~+55°
Power Supply
DC 5V
Power consumption
≤0.2W
Environment Conditions
IP43
Humidity
≤90%
Weight
0.3kg
Size
173*123*35 (mm)

Further detail pls click here for downloading the products specification:

Single band LTE 800MHz RF Repeater.pdf



800MHz Lte 4g Repeater Amplifiers Cellular Network Signal Booster 70dBi 2
800MHz Lte 4g Repeater Amplifiers Cellular Network Signal Booster 70dBi 3
800MHz Lte 4g Repeater Amplifiers Cellular Network Signal Booster 70dBi 4
800MHz Lte 4g Repeater Amplifiers Cellular Network Signal Booster 70dBi 5
800MHz Lte 4g Repeater Amplifiers Cellular Network Signal Booster 70dBi 6
800MHz Lte 4g Repeater Amplifiers Cellular Network Signal Booster 70dBi 7
800MHz Lte 4g Repeater Amplifiers Cellular Network Signal Booster 70dBi 8
800MHz Lte 4g Repeater Amplifiers Cellular Network Signal Booster 70dBi 9
800MHz Lte 4g Repeater Amplifiers Cellular Network Signal Booster 70dBi 10
800MHz Lte 4g Repeater Amplifiers Cellular Network Signal Booster 70dBi 11
800MHz Lte 4g Repeater Amplifiers Cellular Network Signal Booster 70dBi 12
800MHz Lte 4g Repeater Amplifiers Cellular Network Signal Booster 70dBi 13
800MHz Lte 4g Repeater Amplifiers Cellular Network Signal Booster 70dBi 14
800MHz Lte 4g Repeater Amplifiers Cellular Network Signal Booster 70dBi 15
800MHz Lte 4g Repeater Amplifiers Cellular Network Signal Booster 70dBi 16ATNJ Strength & Service
