Home > products > 4G Signal Repeater > GSM LTE 2G 4G Signal Repeater , Vodafone Orange O2 T Mobile Cell Phone Amplifier

GSM LTE 2G 4G Signal Repeater , Vodafone Orange O2 T Mobile Cell Phone Amplifier

Product Details

Place of Origin: China

Brand Name: ATNJ

Certification: CE,ROHS,CCC,TUV,BV, ISO

Model Number: JS-DB800/E900

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: USD+120---145+kit

Packaging Details: Standard neutral packing,52x21x16cm(1 kit), 4kits as 1 carton(53x49x42cm)

Delivery Time: 3-5 work days

Payment Terms: T/T, Western Union,Paypal,Alibaba,Bank transfering.

Supply Ability: 1000+unit+per day.

Get Best Price
Highlight:

O2 4G Signal Repeater

,

GSM LTE 4G Signal Repeater

,

300sqm Cell Phone Amplifier

800MHz Range:
832-862MHz/791-821MHz
900MHz Range:
880-915MHz/925-960MHz
Repeater Gain:
70dB
Color For Choice:
White ,Gold ,Black Customized
Output Power:
17-20dDm
Coverage:
100~300sqm
Connector:
N-Female Connector
Products Type:
Signal Booster, 4g Signal Booster
800MHz Range:
832-862MHz/791-821MHz
900MHz Range:
880-915MHz/925-960MHz
Repeater Gain:
70dB
Color For Choice:
White ,Gold ,Black Customized
Output Power:
17-20dDm
Coverage:
100~300sqm
Connector:
N-Female Connector
Products Type:
Signal Booster, 4g Signal Booster
GSM LTE 2G 4G Signal Repeater , Vodafone Orange O2 T Mobile Cell Phone Amplifier
Product Description
GSM LTE 2G 4G Signal Repeater , Vodafone Orange O2 T Mobile Cell Phone Amplifier 0
  • ATNJ 800/900MHz mobile signal repeater

ATNJ RF repeater with industrial design, combines multi mobile network signals together and improves the mobile voice and data communication, aiming to provide a more cost-effective solution for signal. ATNJ RF repeater is easy to install and maintain, which could help signal providers get fast solution.
  • Selling Point

①Intelligent to guide the installation with LCD .②Real time display the signal strength .
Automatic dormancy when no user make the calling .
③Automatic alarm when installation mistake and provide the according solution .
④Automatic adjust the system gain to avoid the repeater self-excitation .
⑤Initiative reminding when the device was damaged .
⑥Supports from 0.2 to 20MHz bandwidth adjusted(Customized) .
Supports 5G bandwidth, 40MHz,50MHz,60MHz,70MHz,80MHz,90MHz,100MHz(Frequency Bandwidth Customized) .
⑦With WIFI Monitor+Control(Customized),NMS(network management system),Function Optional .
GSM LTE 2G 4G Signal Repeater , Vodafone Orange O2 T Mobile Cell Phone Amplifier 1
SPECIFICATIONS
PARAMETERS
Frequency Range
LTE 800MHz
832-862MHz/791-821MHz

EGSM 900MHz
880-915MHz/925-960MHz
Band Width
LTE 800MHz
30MHz

EGSM 900MHz
35MHz
Gain
68±3dB
Automatic Gain Control
31dB
MGC (Step Attenuation)
20dB@ 1dB/Step
Output Power
20dBm
Spurious Emission
9 kHz -150 kHz/1kHz
≤-36dBm @1kHz

150 kHz - 30 MHz/10kHz
≤-36dBm@10kHz

30 MHz - 1 GHz/100kHz
≤-36dBm@100kHz

1 GHz- 12.75 GHz/1MHz
≤-30dBm@1kHz
ACPR
Uplink Fully comply with 3GPP 36.106

Downlink Fully comply with 3GPP 36.106
Unwanted emissions
Fully comply with 3GPP 36.106
VSWR
≤2
Ripple
LTE 800MHz
≤5dB

GSM 900MHz
≤5dB
Noise Figure
≤9dB
Delay
≤3μs
I/O Impedance
50Q
RF Connector(Customers to Choose)
N-Type (Female)
Operating Temperature
-25°~+55°
Power Supply
DC 5V2A
Power consumption
≤15W
Environment Conditions
IP43
Humidity
≤90%
Weight
0.35kg
Size
145×165×38mm

Further detail pls click here for downloading the products specification:

800+E900MHz A032 mobile signal repeater.pdf



GSM LTE 2G 4G Signal Repeater , Vodafone Orange O2 T Mobile Cell Phone Amplifier 2
GSM LTE 2G 4G Signal Repeater , Vodafone Orange O2 T Mobile Cell Phone Amplifier 3
GSM LTE 2G 4G Signal Repeater , Vodafone Orange O2 T Mobile Cell Phone Amplifier 4
GSM LTE 2G 4G Signal Repeater , Vodafone Orange O2 T Mobile Cell Phone Amplifier 5
GSM LTE 2G 4G Signal Repeater , Vodafone Orange O2 T Mobile Cell Phone Amplifier 6
GSM LTE 2G 4G Signal Repeater , Vodafone Orange O2 T Mobile Cell Phone Amplifier 7
GSM LTE 2G 4G Signal Repeater , Vodafone Orange O2 T Mobile Cell Phone Amplifier 8
GSM LTE 2G 4G Signal Repeater , Vodafone Orange O2 T Mobile Cell Phone Amplifier 9
GSM LTE 2G 4G Signal Repeater , Vodafone Orange O2 T Mobile Cell Phone Amplifier 10
GSM LTE 2G 4G Signal Repeater , Vodafone Orange O2 T Mobile Cell Phone Amplifier 11
GSM LTE 2G 4G Signal Repeater , Vodafone Orange O2 T Mobile Cell Phone Amplifier 12
GSM LTE 2G 4G Signal Repeater , Vodafone Orange O2 T Mobile Cell Phone Amplifier 13
GSM LTE 2G 4G Signal Repeater , Vodafone Orange O2 T Mobile Cell Phone Amplifier 14
GSM LTE 2G 4G Signal Repeater , Vodafone Orange O2 T Mobile Cell Phone Amplifier 15
GSM LTE 2G 4G Signal Repeater , Vodafone Orange O2 T Mobile Cell Phone Amplifier 16
GSM LTE 2G 4G Signal Repeater , Vodafone Orange O2 T Mobile Cell Phone Amplifier 17
GSM LTE 2G 4G Signal Repeater , Vodafone Orange O2 T Mobile Cell Phone Amplifier 18
Product Usage
GSM LTE 2G 4G Signal Repeater , Vodafone Orange O2 T Mobile Cell Phone Amplifier 19
  •

    • Product usage introduction



How It Works

Wireless network signal travels through the air in the form of waves. The outdoor antenna is designed to receive the weak signal from the air and transmit it to the indoor booster. The booster amplifies the signal based on its frequency and emits the amplified signal through the indoor antenna making it available for use.
Packing&Shipping
Packing
Usually we provide neutral packing for goods to oversea.

GSM LTE 2G 4G Signal Repeater , Vodafone Orange O2 T Mobile Cell Phone Amplifier 20
GSM LTE 2G 4G Signal Repeater , Vodafone Orange O2 T Mobile Cell Phone Amplifier 21
GSM LTE 2G 4G Signal Repeater , Vodafone Orange O2 T Mobile Cell Phone Amplifier 22



GSM LTE 2G 4G Signal Repeater , Vodafone Orange O2 T Mobile Cell Phone Amplifier 23
Shipping
We will send your parcel as soon as possible after payment confirmed within 48 hours.
●Please provide your correct address,full name,and zip code.
●We generally would declare the parcel with lower value to avoid or lessen the Customs Tax.Import Tax is not
including in the price. When it happens, it is buyers responsibility to pay for the tax and custom clearance.
●Shipping is out of our control. If you want to get the product fast, please choose fast shipping methods, like Fedex, UPS and DHL. If you find the package is beyond promised delivered time, please contact us, we will contact with the carriers and find out the reason.
Company Introduction
Shenzhen ATNJ Communication Technology Company was founded in Nanshan District, Shenzhen in 2010 with over 900sqm factory. ATNJ focuses on the production and development of micro power signal booster, wireless signal repeater, Indoor Signal Distribution System and antenna series. With professional engineers, workers and with senior management personnel, the group maintains high-speed development. Meanwhile, the Up-to-date facilities and technology end sure the business long-term development. With the rapid development of the company, ATNJ moved to Guangming District, Shenzhen in 2016 with a bigger factory over 2800sqm and over 50 workers. In its stage of rapid development, ATNJ advertised its products by attending trade exhibitions oversea, cooperating with many platforms like Made-in-China, Alibaba, Global Sources and so on. Especially, ATNJ attended Mobile World Congress in Spain, which made ATNJ well known in the world and through MWC, ATNJ started to cooperate with many oversea companies. Nowadays, ATNJ not only produces and develops high-quality home use signal booster and high power wireless repeater, but also expands its business scope to cooperate with signal operators, provide signal coverage solution for large area like residential area, office building, supermarket, underground garage and rural areas. With the populization of signal repeater, users have more requirements for the functions of the signal repeater. In 2020, ATNJ developed smarter digital module signal repeater with WIFI connection monitoring function, with which users could control the signal repeater and watch the siganl repeater working situation with their mobile phone. Signal repeaters with WAN connection/Bluetooth connection/USB connection were developed at the same time. In 2021, 5G signal booster was developed and put into Chinese market successfully. In addition, ATNJ starts to upgrade the signal booster from analog module to digital module, with which the products (micro power signal booster, wireless signal repeater, Indoor Signal Distribution System) could be operated and controlled with WIFI connection, WAN port, USB port and SIM card. What‘s more, more functions are equipped in our products, like band selective, sub bands, OLED screen display, MGC. With the progress of science and technology of ATNJ, easier use and more functional signal boosters have being developed.
GSM LTE 2G 4G Signal Repeater , Vodafone Orange O2 T Mobile Cell Phone Amplifier 24
GSM LTE 2G 4G Signal Repeater , Vodafone Orange O2 T Mobile Cell Phone Amplifier 25
GSM LTE 2G 4G Signal Repeater , Vodafone Orange O2 T Mobile Cell Phone Amplifier 26
GSM LTE 2G 4G Signal Repeater , Vodafone Orange O2 T Mobile Cell Phone Amplifier 27

ATNJ Strength & Service

Highly qualified communication technology Engineers. ATNJ brings together a team of engineers with more than ten years of working experience in communication industry, who are engaged in signal booster R&D, design, debugging, testing, and its pre-production to ensure it could comply with International Standards. For the sustainable development of the company, some young engineers are also employed. Because of their hard work, the ATNJ's products can be continuously updated and iterated.
Satisfactory after-sales service. ATNJ provides 3-year warranty for all the main signal repeater, and 3-month warranty for
accessories. Within the warranty period, ATNJ provides free repairment service, and customers only need to pay for the freight. In addition, within one month after the customer receives the product, ATNJ is responsible for all non-human damage faults.
Contact us and place order now, to have better signal, better life.

We are manufacturer, and have our own factory.



FAQ:

1. Are you trading company or manufacturer ? Could I use our own logo and label? We are factory, with trading service. We provide OEM/OEM service.

2. Can I have a sample order? What is your MOQ?
Yes, we welcome sample order to test and check quality. MOQ is 1 for normal products.

3:  Is it easy to set up your items?
A: Yes. We have a user manual and support technical support 24/7.

4. What is your warranty time?
We promise 3-year warranty for all products shipped from us. Man-made sabotage and natural factors are not within the scope of warranty.
