ATNJ Dual Band 1800/2100MHz 3G 4G Signal Repeater Kit with 70dB Gain

ATNJ Dual Band 1800/2100MHz 3G 4G Signal Repeater Kit with 70dB Gain

Brand Name: ATNJ
Model Number: ATNJ-AT1800/2100
Price: $94/sets 1-99 sets
Detail Information
Place of Origin:
Guangdong, China
Type:
3/4G Signal Booster
Network:
4g, GSM, 3G, LTE, EGSM, DCS, 5G, 2G
Key Words:
2g 3g 4g Repeater
Suitable:
Global Applicatioin For Home/office/apartment... Use
Frequency:
1710-1785MHz /1805-1880MHz ,1920-1980MHz/2110-2170MHz
Cellular Networks:
2G/3G
Coverage:
100--500m2
Weight:
1kg
Size:
225x140x35 (mm)
Material:
Aluminium
Gain:
70db
Warranty:
3 Years
Highlight:

3G 4G signal repeater

,

Dual band signal booster

,

70dB gain repeater kit

Product Description
ATNJ Dual Band 1800/2100MHz 3G 4G Signal Repeater Kit with 70dB Gain
Product Overview
ATNJ Dual Band 1800/2100MHz 3G 4G Signal Repeater Kit with 70dB Gain 0 ATNJ Dual Band 1800/2100MHz 3G 4G Signal Repeater Kit with 70dB Gain 1 ATNJ Dual Band 1800/2100MHz 3G 4G Signal Repeater Kit with 70dB Gain 2 ATNJ Dual Band 1800/2100MHz 3G 4G Signal Repeater Kit with 70dB Gain 3 ATNJ Dual Band 1800/2100MHz 3G 4G Signal Repeater Kit with 70dB Gain 4
Product Attributes
Attribute Value
Type 3/4G signal booster
Network 4g, GSM, 3G, LTE, EGSM, DCS, 5G, 2G
Frequency 1710-1785MHz /1805-1880MHz, 1920-1980MHz/2110-2170MHz
Cellular Networks 2G/3G
Coverage 100-500m²
Weight 1kg
Size 225x140x35 (mm)
Material Aluminium
Gain 70db
Warranty 3 Years
Technical Specifications
ATNJ Dual Band 1800/2100MHz 3G 4G Signal Repeater Kit with 70dB Gain 5
Specifications
Frequency Range Uplink 1710-1785MHz & 1920-1980MHz
Downlink 1805-1880MHz & 2110-2170MHz
Frequency Bandwidth (3dB Bandwidth) 75MHz & 60MHz
Gain ≥ 70dB
Automatic gain control (Step Attenuation) 31dB @ 1dB/ Step
Auto Gain Control 20dB Min.
Output Power 17-23dbm
Spurious Emission ≤ -15dBm/30kHz
9kHz~1GHz: ≤ -36dBm/30kHz
1GHz~12.75GHz: ≤ -30dBm/30kHz
Inter-Modulation Attenuation ACPR ≤ -38dBc / 30kHz (measured under rated output power)
In-band Ripple ≤ 5dB
Voltage Standing Wave Ratio <=2
I/O Impedance 50 Ω
Noise Figure ≤ 5dB
System Delay ≤ 5μs
RF Connector SMA-Type (Female)
Operating Temperature Operation: -10°C ~ +55°C / Storage: -20°C ~ +60°C
Power Supply AC 220V±20%, 50/60Hz(AC 220V/ DC9V/9A power adapter)
Dimensions 225*140*35 (mm)
Weight 1 kg
Alarm Monitoring System Alarm for uplink self-oscillation
Indication LED Power supply, Run, Alarm
Key Features
ATNJ Dual Band 1800/2100MHz 3G 4G Signal Repeater Kit with 70dB Gain 6
  • Intelligent to guide the installation with LCD
  • Real time display the signal strength
  • Automatic dormancy when no user make the calling
  • Initiative reminding when device damaged
  • Automatic detect the installation mistake and provide the corresponding solution with LCD
How It Works
ATNJ Dual Band 1800/2100MHz 3G 4G Signal Repeater Kit with 70dB Gain 20

Wireless network signal travels through the air in the form of waves. The outdoor antenna is designed to receive the good signal from the outdoor and transmit it to the indoor booster. The booster amplifies the signal based on its frequency and emits the amplified signal through the indoor antenna making it available for use.
