Product Description:
The Signal Repeater comes with an Auto Shut Off feature that helps to save energy and reduce power consumption. This feature ensures that the device automatically shuts off when it is not in use, thereby reducing the risk of overworking and prolonging the lifespan of the device.
The Band Selective Repeater is easy to install and use. It comes with a user manual that provides step-by-step instructions on how to set up and operate the device. You do not need any special skills or tools to install the device. All you need is a stable power supply, and you are good to go.
The Band Selective Repeater is designed to provide stable and reliable signal amplification. It can effectively amplify the signal without causing any interference. This ensures that you get a strong and stable signal at all times.
In conclusion, the Band Selective Repeater is a must-have device for anyone who needs a reliable and stable signal booster. It is easy to install and operate, energy-efficient. With this device, you can enjoy seamless internet connectivity and clear voice calls without any interruption.
Features:
① Intelligent to guide the installation with LCD.
② Real-time displays the signal strength.
③ Automatic dormancy when no user makes the call.
④ Automatic alarm when installation mistake and provide the appropriate solution.
⑤ Automatic adjust the system gain to avoid the repeater self-excitation.
⑥ Initiative reminding when the device was damaged.
⑦ WIFIMonitor+Control(Customized), NMS(network management system), Function Optional.
Technical Parameters:
| AS-140-135-G |
900 MHz |
| Frequency Range |
Uplink |
880-915MHz |
| Downlink |
925-960MHz |
| Number of Sub-Bands |
1 Sub-Band |
| Bandwidth |
35MHz, each Sub-Band support (0.2 - 20 MHz adjustable) |
| Max Gain |
Uplink |
65dBm |
| Downlink |
70dBm |
| Manual Gain Control |
31 dB in step of 1 dB |
| Automatic Gain Control |
≧ 20 dB |
| Gain Flatness |
≦ ±2 dB (peak-to-peak) |
| Max. Input Power Without Damage |
0 dBm |
| Output Power |
Uplink |
17 ±2dBm |
| Downlink |
20 ±2dBm |
| Operating band unwanted emissions |
Comply with 3GPP |
| Spurious Emission |
9kHz~1GHz |
≦ -36dBm |
| 1GHz~12.75GHz |
≦ -30dBm |
| ACPR |
±20MHz |
Uplink≦-36dBc/Downlink≦-45dBc |
| ±40MHz |
Uplink≦-45dBc/Downlink≦-50dBc |
| EVM |
≦ 8 |
| Frequecy Stability |
≦ ±0.01 ppm |
| Noise Figure |
≦ 8 dB |
| VSWR |
≦ 2 |
| Group Delay |
≦ 3 μs |
| RF Connector |
N-Female |
| Impedance |
50 Ω |
| Power Supply |
Input: AC 100~240 V; Output: DC 5 V/ 5 A |
| Power Consumption |
≦ 75 W |
| Dimensions |
234*230*52mm |
| Weight |
≦ 5 Kg |
| IP Rating |
IP40 |
| Operating Temperature |
-25 ℃ to 55 ℃ |
Control &
Monitoring |
Local |
WIFI/Type-C port |
| Remote |
Optional |
A mobile phone signal repeater provides the ultimate solution in any area where cellular communications can not work well due to leak of signals. The repeater device features easy installation & operation, build-in indoor antenna and no interference.
It could also improve indoor electromagnetism environments, protract cellular battery life and reduce radiation of cellphones. A mobile phone repeater is ideal for house, home, office use.
The repeater makes the signal stronger in places with poor signal coverage such as:
1) Underground areas: basements, parking lots, tunnels;
2) Other places where cellular signal is shielded by metal or concrete walls: offices, supermarkets, cinemas, hotels;
3) Places distant from the BTS like private houses.
