Tri Band Repeater
>
Digital Band selective 2G 3G Cell Phone Repeater , 4g Amplifier 5g Mobile Phone Signal Detector

Digital Band selective 2G 3G Cell Phone Repeater , 4g Amplifier 5g Mobile Phone Signal Detector

Brand Name: ATNJ
Model Number: JS-D-DWL
MOQ: 1
Price: USD+360-480+kit
Packaging Details: Standard neutral packing,48x46x18cm(1 kit),
Payment Terms: T/T, Western Union,Paypal,Alibaba,Bank transfering.
Detail Information
Place of Origin:
China
Certification:
CE,ROHS,CCC,TUV,BV, ISO
Band8 E900 Frequency Range::
880-915MHz/925-960MHz
Band3 1800MHz Frequency Range::
1710-1785MHz / 1805-1880MHz
Band1 2100MHz Frequency Range::
1920-1980MHz / 2110-2170MHz
Bandwidth:
35MHz&75MHz&60MHz, Supports Each Band 1 Sub-bands From 0.2 To 20MHz Bandwidth Adjusted
Local Control:
WIFI/ Type-C Port, Bandwidth Adjustment Could Be Done By Type-C Only
Remote Control:
Cloud WEB Platform By SIM Card
Device Gain:
Uplink : 65dB Downlink : 70dB
Device Output Power:
Uplink : 13dBm Downlink : 20dBm
Color For Choice:
Black, White Or Customized
Products Type:
Signal Amplifier, Mobile Network Booster 2g 3g 4g Lte 5g
Coverage Area:
Up To 500 Square Meters
Products Name:
Cell Phone Booster
Supply Ability:
1000+unit+per day.
High Light:

CCC Cell Phone Repeater

,

65dB Cell Phone Repeater

,

960MHz Mobile Phone Signal Detector

Product Description

2G 3G 4G repetidor de celular 4g amplificador celular repetidor 5g mobile phone signal detector





General :



The Repeater provides an affordable solution to solve the indoor signal coverage problems due to signal fading and attenuation caused by architecture obstacles. And its easy installation and maintenance can help carrier get fast return.
The repeater is working as a relay between the BTS and mobiles. It picks up the strongest signal from BTS via the Donor Antenna, linearly amplifies the signal and then retransmits it via the Indoor Signal Distribution System to the weak/blind coverage area. And the mobile signal is also amplified and retransmitted to the BTS via the opposite direction.



Specification

SPECIFICATIONS PARAMETERS
Frequency Range Band8 E900MHz

880-915MHz/925-960MHz

Band3 LTE 1800MHz

1710MHz -1785MHz/

1805MHz- 1880MHz

Band1 UMTS2100 < E2100

1920-1980MHz/2110-2170MHz

Band Width Band8 E900MHz Supports 1*20MHz from 0.2 to 20MHz
Band3 LTE 1800MHz Supports 1*20MHz from 0.2 to 20MHz
Band1 UMTS2100 < E2100 Supports 1*20MHz from 0.2 to 20MHz
Gain Uplink 65dB
Downlink 70dB
Automatic Gain Control 31dB
MGC (Step Attenuation) 31dB @ 1dB/ Step
Output Power Uplink 13dBm
Downlink 20dBm
Spurious Emission 9 kHz -150 kHz/1kHz ≤ - 36dBm
150 kHz - 30 MHz/10kHz ≤-36dBm
30 MHz - 1 GHz/100kHz ≤- 36dBm
1 GHz- 12.75 GHz/1MHz ≤ - 30dBm
ACPR Uplink Fully comply with 3GPP 36.106
Downlink Fully comply with 3GPP 36.106
Unwanted emissions Fully comply with 3GPP 36.106
VSWR ≤ 2
Ripple E900MHz ≤ 3dB
LTE 1800MHz ≤ 2dB / 3.84MHz
UMTS2100 < E2100MHz ≤ 3dB @ BW Config
Noise Figure ≤ 8dB
Delay ≤ 3.5 us
I/O Impedance 50Q
RF Connector(Customers to Choose) N-Type (Female)
Operating Temperature -10° ~ +55°
Power Supply 100 - 265V
Power consumption 300W
Environment Conditions IP55
Humidity ≤ 90%
Weight 5kg
Size 416x268x71 mm

Further detail pls click here for downloading the products specification:

E900+1800+2100MHz Selective Repeater.pdf

Digital Band selective 2G 3G Cell Phone Repeater , 4g Amplifier 5g Mobile Phone Signal Detector 0



Digital Band selective 2G 3G Cell Phone Repeater , 4g Amplifier 5g Mobile Phone Signal Detector 1
Digital Band selective 2G 3G Cell Phone Repeater , 4g Amplifier 5g Mobile Phone Signal Detector 2
Digital Band selective 2G 3G Cell Phone Repeater , 4g Amplifier 5g Mobile Phone Signal Detector 3
Digital Band selective 2G 3G Cell Phone Repeater , 4g Amplifier 5g Mobile Phone Signal Detector 4
Digital Band selective 2G 3G Cell Phone Repeater , 4g Amplifier 5g Mobile Phone Signal Detector 5
Digital Band selective 2G 3G Cell Phone Repeater , 4g Amplifier 5g Mobile Phone Signal Detector 6
Digital Band selective 2G 3G Cell Phone Repeater , 4g Amplifier 5g Mobile Phone Signal Detector 7
Digital Band selective 2G 3G Cell Phone Repeater , 4g Amplifier 5g Mobile Phone Signal Detector 8
Digital Band selective 2G 3G Cell Phone Repeater , 4g Amplifier 5g Mobile Phone Signal Detector 9
Digital Band selective 2G 3G Cell Phone Repeater , 4g Amplifier 5g Mobile Phone Signal Detector 10
Digital Band selective 2G 3G Cell Phone Repeater , 4g Amplifier 5g Mobile Phone Signal Detector 11
Digital Band selective 2G 3G Cell Phone Repeater , 4g Amplifier 5g Mobile Phone Signal Detector 12
Digital Band selective 2G 3G Cell Phone Repeater , 4g Amplifier 5g Mobile Phone Signal Detector 13
Digital Band selective 2G 3G Cell Phone Repeater , 4g Amplifier 5g Mobile Phone Signal Detector 14
Digital Band selective 2G 3G Cell Phone Repeater , 4g Amplifier 5g Mobile Phone Signal Detector 15
Company Introduction
Digital Band selective 2G 3G Cell Phone Repeater , 4g Amplifier 5g Mobile Phone Signal Detector 16
Shenzhen ATNJ Communication Technology Co.,LTD
Shenzhen ATNJ Communication Technology Company was founded in Nanshan District, Shenzhen in 2010 with over 900sqm factory. ATNJ focuses on the production and development of micro power signal booster, wireless signal repeater, Indoor Signal Distribution System and antenna series. With professional engineers, workers and with senior management personnel, the group maintains high-speed development.
Meanwhile, the Up-to-date facilities and technology end sure the business long-term development. With the rapid development of the company, ATNJ moved to Guangming District, Shenzhen in 2016 with a bigger factory over 2800sqm and over 50 workers.
In its stage of rapid development, ATNJ advertised its products by attending trade exhibitions oversea, cooperating with many platforms like Made-in-China, Alibaba, Global Sources and so on. Especially, ATNJ attended Mobile World Congress in Spain, which made ATNJ well known in the world and through MWC, ATNJ started to cooperate with many oversea companies.
Nowadays, ATNJ not only produces and develops high-quality home use signal booster and high power wireless repeater, but also expands its business scope to cooperate with signal operators, provide signal coverage solution for large area like residential area, office building, supermarket, underground garage and rural areas.
With the populization of signal repeater, users have more requirements for the functions of the signal repeater. In 2020, ATNJ developed smarter digital module signal repeater with WIFI connection monitoring function, with which users could control the signal repeater and watch the siganl repeater working situation with their mobile phone. Signal repeaters with WAN connection/Bluetooth connection/USB connection were developed at the same time.
In 2021,5G signal booster was developed and put into Chinese market successfully. In addition, ATNJ starts to upgrade the signal booster from analog module to digital module, with which the products (micro power signal booster, wireless signal repeater,Indoor Signal Distribution System) could be operated and controlled with WIFI connection, WAN port, USB port and SIM card.
What‘s more, more functions are equipped in our products, like band selective, sub bands, OLED screen display, MGC.With the progress of science and technology of ATNJ, easier use and more functional signal boosters have being developed.
Digital Band selective 2G 3G Cell Phone Repeater , 4g Amplifier 5g Mobile Phone Signal Detector 17
Digital Band selective 2G 3G Cell Phone Repeater , 4g Amplifier 5g Mobile Phone Signal Detector 18
Digital Band selective 2G 3G Cell Phone Repeater , 4g Amplifier 5g Mobile Phone Signal Detector 19

ATNJ Strength & Service

Highly qualified communication technology Engineers. ATNJ brings together a team of engineers with more than ten years of working experience in communication industry, who are engaged in signal booster R&D, design, debugging, testing, and its pre-production to ensure it could comply with International Standards. For the sustainable development of the company, some young engineers are also employed. Because of their hard work, the ATNJ's products can be continuously updated and iterated.
Satisfactory after-sales service.
ATNJ provides 3-year warranty for all the main signal repeater, and 3-month warranty for accessories. Within the warranty period, ATNJ provides free repairment service, and customers only need to pay for the freight.Inaddition, within one month after the customer receives the product, ATNJ is responsible for all non-human damage faults.
Contact us and place order now, to have better signal, better life.



FAQ



Q1:Do you have CE or any other certification?
A:Yes,we CE, ROHS and CCC certification,etc.
Q2:Can you give me a discount?
A:Please discuss with our sales.
Q3:How about gain and output power of your device?
A:Different models, gain and output power aredifferent,for more details, please contact us.
Q4:How long is warranty period?
A:The warranty is 36months. And we offer 7*24technical support
Q5:how many square meters can be covered?
A:For different models, the covered square meters are different.
Q6: How does a cell phone signal booster for office differ from residential signal boosters?
A building booster, like the kind using in an office installation, differs from a residential booster in that they can cover a much larger area. A cell phone signal booster that could be used at home would cover a much smaller area, needs less power and should be easy to self-install. A cell phone signal booster for office needs to cover a larger area and be able to handle more users and needs to be able to power a full DAS system, which means multiple antennas covering the entire office is needed.
