ATNJ 1800MHz Mobile 4G Signal Repeater Booster SMA / Female for Phone

Name: ATNJ 1800MHz Mobile 4G Signal Repeater Booster SMA / Female for Phone
Brand: Shenzhen Atnj Communication Technology Co., Ltd.
SKU: AS-D3
Price: 44.00 USD
Availability: InStock

Basic Properties

Place of Origin: China

Brand Name: ATNJ

Certification: CE,ROHS，CCC，TUV,BV， ISO

Model Number: AS-D3

Trading Properties

Minimum Order Quantity: 5Pcs

Price: USD+40---49+kit

Payment Terms: T/T, Western Union,Paypal,Alibaba,Bank transfering.

Supply Ability: 1000+unit+per day.

2100MHz 4G Signal Repeater

800MHz 4G Signal Repeater

75MHz 4G Signal Repeater

Specifications

Frequency Range:	1710-1785MHz/1805-1880MHz	Gain:	70dB
Output power:	17dBm	AGC Intelligent function:	Done,31dB @ 1dB/ Step
RF Connect Type:	SMA/Female	Weight:	1.85kg
Packing size:	54x19x16cm	Products name:	4g Signal Booster, 4g Mobile Phone Repeater Amplifier
High Light:	4G Signal Repeater 75MHz , 17dBm 4G Signal Repeater , SMA 4G Signal Booster

Product Description

2G 4G 1800MHz Cell Phone Signal Repeater Customized White Color

1800MHz Cell Signal Repeater 2G/4G Mobile Signal Booster mobile Signal Amplifier

ATNJ RF repeater with industrial design, combines multi mobile network signals together and improves the mobile voice and data communication, aiming to provide a more cost-effective solution for signal. ATNJ RF repeater is easy to install and maintain, which could help signal providers get fast solution.

Technical Specifications

Specifications		Parameters
Frequency Range (Customers to Choose)	Uplink	1710-1785Mhz
	Downlink	1805-1880Mhz
Frequency Bandwidth		75MHz
Gain		70dB
Automatic gain control (Step Attenuation)		31dB @ 1dB/ Step
Auto Gain Control		20dB Min.
Output Power(Customers to Choose)		20dBm
Spurious Emission		≤ -15dBm/30kHz
		9kHz~1GHz: ≤ -36dBm/30kHz
		1GHz~12.75GHz: ≤ -30dBm/30kHz
Inter-Modulation Attenuation ACPR		≤ -40dBc / 30kHz (measured under rated output power)
In-band Ripple		≤ 3dB
VSWR		<=2
I/O Impedance		50 Ω
Noise Figure		≤ 5dB
System Delay		≤ 5μs
RF Connector(Customers to Choose)		SMA (Female)
Operating Temperature		Operation: - 10°C ~ + 55°C / Storage: -20°C ~ +60°C
Power Supply		AC 110~220V±20%, 50/60Hz(AC 220V/ DC5V/2A power adapter)
Dimensions		16513040 (mm)
Weight		≤0.8 kg(Net)
Alarm Monitoring System		Alarm for uplink self-oscillation
Indication LED		Power supply

Further detail pls click here for downloading the products specification:

Single band DCS 1800MHz RF Repeater.pdf

Selling Point

①Intelligent to guide the installation with LCD .②Real time display the signal strength .
Automatic dormancy when no user make the calling .

③Automatic alarm when installation mistake and provide the according solution .

④Automatic adjust the system gain to avoid the repeater self-excitation .

⑤Initiative reminding when the device was damaged .

⑥Supports from 0.2 to 20MHz bandwidth adjusted(Customized) .

Supports 5G bandwidth, 40MHz,50MHz,60MHz,70MHz,80MHz,90MHz,100MHz(Frequency Bandwidth Customized) .

⑦With WIFI Monitor+Control(Customized),NMS(network management system),Function Optional .

Product Description

ATNJ 1800MHz Mobile 4G Signal Repeater Booster SMA / Female for Phone 0

How It Works

Wireless network signal travels through the air in the form of waves. The outdoor antenna is designed to receive the weak signal from the air and transmit it to the indoor booster. The booster amplifies the signal based on its frequency and emits the amplified signal through the indoor antenna making it available for use.

ATNJ 1800MHz Mobile 4G Signal Repeater Booster SMA / Female for Phone 7

ATNJ 1800MHz Mobile 4G Signal Repeater Booster SMA / Female for Phone 9

ATNJ 1800MHz Mobile 4G Signal Repeater Booster SMA / Female for Phone 10

Shipping

●We will send your parcel as soon as possible after payment confirmed within 48 hours.

●Please provide your correct address,full name,and zip code.

●We generally would declare the parcel with lower value to avoid or lessen the Customs Tax.Import Tax is not

including in the price. When it happens, it is buyers responsibility to pay for the tax and custom clearance.

●Shipping is out of our control. If you want to get the product fast, please choose fast shipping methods, like Fedex, UPS and DHL. If you find the package is beyond promised delivered time, please contact us, we will contact with the carriers and find out the reason.

Company Introduction

Shenzhen ATNJ Communication Technology Company was founded in Nanshan District, Shenzhen in 2010 with over 900sqm factory. ATNJ focuses on the production and development of micro power signal booster, wireless signal repeater, Indoor Signal Distribution System and antenna series. With professional engineers, workers and with senior management personnel, the group maintains high-speed development. Meanwhile, the Up-to-date facilities and technology end sure the business long-term development. With the rapid development of the company, ATNJ moved to Guangming District, Shenzhen in 2016 with a bigger factory over 2800sqm and over 50 workers. In its stage of rapid development, ATNJ advertised its products by attending trade exhibitions oversea, cooperating with many platforms like Made-in-China, Alibaba, Global Sources and so on. Especially, ATNJ attended Mobile World Congress in Spain, which made ATNJ well known in the world and through MWC, ATNJ started to cooperate with many oversea companies. Nowadays, ATNJ not only produces and develops high-quality home use signal booster and high power wireless repeater, but also expands its business scope to cooperate with signal operators, provide signal coverage solution for large area like residential area, office building, supermarket, underground garage and rural areas. With the populization of signal repeater, users have more requirements for the functions of the signal repeater. In 2020, ATNJ developed smarter digital module signal repeater with WIFI connection monitoring function, with which users could control the signal repeater and watch the siganl repeater working situation with their mobile phone. Signal repeaters with WAN connection/Bluetooth connection/USB connection were developed at the same time. In 2021, 5G signal booster was developed and put into Chinese market successfully. In addition, ATNJ starts to upgrade the signal booster from analog module to digital module, with which the products (micro power signal booster, wireless signal repeater, Indoor Signal Distribution System) could be operated and controlled with WIFI connection, WAN port, USB port and SIM card. What‘s more, more functions are equipped in our products, like band selective, sub bands, OLED screen display, MGC. With the progress of science and technology of ATNJ, easier use and more functional signal boosters have being developed.

FAQ:

1. Are you trading company or manufacturer ? Could I use our own logo and label?

We are factory, with trading service. We provide OEM/OEM service.

2. Can I have a sample order? What is your MOQ?
Yes, we welcome sample order to test and check quality. MOQ is 1 for normal products.

3. Is it easy to set up your items?
A: Yes. We have a user manual and support technical support 24/7.

4. What is your warranty time?
We promise 3-year warranty for all products shipped from us. Man-made sabotage and natural factors are not within the scope of warranty.

5. Please feel free to contact us if any other questions.
