ATNJ Dual Band Repeater Multi-Network Signal Solution for Improved Coverage

5Pcs
MOQ
USD+70---85+kit
Price
ATNJ Dual Band Repeater Multi-Network Signal Solution for Improved Coverage
Features Gallery Product Description Request A Quote
Features
Specifications
Band8 900MHz Frequency Range: 890-915MHz / 935-960MHz
Band3 1800MHz Frequency Range: 1710-1785MHz / 1805-1880MHz
Products Type: GSM Signal Repeater
Color: Grey And Customized
AGC Intelligent Function: Done,31dB @ 1dB/ Step
ALC Intelligent Function: Done
MGC: Done
Packing Size: 52x21x16cm
Highlight:

31dB Signal Booster Amplifier

,

Signal Booster Amplifier 1800MHz

,

GSM Signal Booster Amplifier

Basic Infomation
Place of Origin: China
Brand Name: ATNJ
Certification: CE,ROHS,CCC,TUV,BV, ISO
Model Number: JS-DB900/1800P
Payment & Shipping Terms
Packaging Details: Standard neutral packing,52x21x16cm(1 kit), 6kits as 1 carton(53x49x42cm)
Delivery Time: 3-5 work days
Payment Terms: T/T, Western Union,Paypal,Alibaba,Bank transfering.
Supply Ability: 1000+unit+per day.
Product Description
Product Description
ATNJ Dual Band Repeater Multi-Network Signal Solution for Improved Coverage 0
  • ATNJ Dual band 900/1800MHz mobile signal repeater

  •

ATNJ GSM repeater with industrial design, combines multi mobile network signals together and improves the mobile voice and data
communication, aiming to provide a more cost-effective solution for signal. Our repeater is easy to install and maintain,
which could help customer get fast solution.
SPECIFICATIONS
PARAMETERS
Frequency Range
GSM 900MHz
890-915MHz/935-960MHz
DCS 1800MHz
1710-1785MHz/1805-1880MHz
Band Width
GSM 900MHz
25MHz
DCS 1800MHz
75MHz
Gain
68±2dB
Automatic Gain Control
31dB
MGC (Step Attenuation)
31dB@ 1dB/Step
Output Power
23dBm
Spurious Emission
9 kHz -150 kHz/1kHz
≤-36dBm @1kHz
150 kHz - 30 MHz/10kHz
≤-36dBm@10kHz
30 MHz - 1 GHz/100kHz
≤-36dBm@100kHz
1 GHz- 12.75 GHz/1MHz
≤-30dBm@1kHz
ACPR
Uplink Fully comply with 3GPP 36.106
Downlink Fully comply with 3GPP 36.106
Unwanted emissions
Fully comply with 3GPP 36.106
VSWR
≤2
Ripple
GSM 900MHz
≤5dB
UMTS 2100MHz
≤5dB
Noise Figure
≤9dB
Delay
≤3μs
I/O Impedance
50Q
RF Connector(Customers to Choose)
SMA-Type (Female)
Operating Temperature
-25°~+55°
Power Supply
DC 5V3A
Power consumption
≤15W
Environment Conditions
IP43
Humidity
≤90%
Weight
0.35kg
Size
145×165×38mm

Further detail pls click here for downloading the products specification:

900+1800MHz 006 mobile signal repeater.pdf

ATNJ Dual Band Repeater Multi-Network Signal Solution for Improved Coverage 1
ATNJ Dual Band Repeater Multi-Network Signal Solution for Improved Coverage 2
ATNJ Dual Band Repeater Multi-Network Signal Solution for Improved Coverage 3
ATNJ Dual Band Repeater Multi-Network Signal Solution for Improved Coverage 4
ATNJ Dual Band Repeater Multi-Network Signal Solution for Improved Coverage 5
ATNJ Dual Band Repeater Multi-Network Signal Solution for Improved Coverage 6
ATNJ Dual Band Repeater Multi-Network Signal Solution for Improved Coverage 7
ATNJ Dual Band Repeater Multi-Network Signal Solution for Improved Coverage 8
ATNJ Dual Band Repeater Multi-Network Signal Solution for Improved Coverage 9
ATNJ Dual Band Repeater Multi-Network Signal Solution for Improved Coverage 10
ATNJ Dual Band Repeater Multi-Network Signal Solution for Improved Coverage 11
ATNJ Dual Band Repeater Multi-Network Signal Solution for Improved Coverage 12
00:03

03:16

ATNJ Dual Band Repeater Multi-Network Signal Solution for Improved Coverage 13
ATNJ Dual Band Repeater Multi-Network Signal Solution for Improved Coverage 14
ATNJ Dual Band Repeater Multi-Network Signal Solution for Improved Coverage 15
ATNJ Dual Band Repeater Multi-Network Signal Solution for Improved Coverage 16
ATNJ Dual Band Repeater Multi-Network Signal Solution for Improved Coverage 17
ATNJ Dual Band Repeater Multi-Network Signal Solution for Improved Coverage 18
ATNJ Dual Band Repeater Multi-Network Signal Solution for Improved Coverage 19
ATNJ Dual Band Repeater Multi-Network Signal Solution for Improved Coverage 20
Product Usage
ATNJ Dual Band Repeater Multi-Network Signal Solution for Improved Coverage 21
  •

    •

How It Works


Wireless network signal travels through the air in the form of waves. The outdoor antenna is designed to receive the good signal from the outdoor and transmit it to the indoor booster. The booster amplifies the signal based on its frequency and emits the amplified signal through the indoor antenna making it available for use.
Selling Point
①Intelligent to guide the installation with LCD .②Real time display the signal strength .
Automatic dormancy when no user make the calling .
③Automatic alarm when installation mistake and provide the according solution .
④Automatic adjust the system gain to avoid the repeater self-excitation .
⑤Initiative reminding when the device was damaged .
⑥Supports from 0.2 to 20MHz bandwidth adjusted(Customized) .
Supports 5G bandwidth, 40MHz,50MHz,60MHz,70MHz,80MHz,90MHz,100MHz(Frequency Bandwidth Customized) .
⑦With WIFI Monitor+Control(Customized),NMS(network management system),Function Optional .
ATNJ Dual Band Repeater Multi-Network Signal Solution for Improved Coverage 22
Packing&Shipping
Packing

Usually we provide neutral packing for goods to oversea.
ATNJ Dual Band Repeater Multi-Network Signal Solution for Improved Coverage 23
ATNJ Dual Band Repeater Multi-Network Signal Solution for Improved Coverage 24
ATNJ Dual Band Repeater Multi-Network Signal Solution for Improved Coverage 25
ATNJ Dual Band Repeater Multi-Network Signal Solution for Improved Coverage 26
Shipping
●We will send your parcel as soon as possible after payment confirmed within 48 hours. ●Please provide your correct address,full name,and zip code.
●We generally would declare the parcel with lower value to avoid or lessen the Customs Tax.Import Tax is not
including in the price. When it happens, it is buyers responsibility to pay for the tax and custom clearance.
●Shipping is out of our control. If you want to get the product fast, please choose fast shipping methods, like Fedex, UPS and DHL. If you find the package is beyond promised delivered time, please contact us, we will contact with the carriers and find out the reason.
Company Introduction
Shenzhen ATNJ Communication Technology Company was founded in Nanshan District, Shenzhen in 2010 with over 900sqm factory. ATNJ focuses on the production and development of micro power signal booster, wireless signal repeater, Indoor Signal Distribution System and antenna series. With professional engineers, workers and with senior management personnel, the group maintains high-speed development.
Meanwhile, the Up-to-date facilities and technology end sure the business long-term development. With the rapid development of the company, ATNJ moved to Guangming District, Shenzhen in 2016 with a bigger factory over 2800sqm and over 50 workers.
In its stage of rapid development, ATNJ advertised its products by attending trade exhibitions oversea, cooperating
with many platforms like Made-in-China, Alibaba, Global Sources and so on. Especially, ATNJ attended Mobile World Congress in Spain, which made ATNJ well known in the world and through MWC, ATNJ started to cooperate with many oversea companies.
Nowadays, ATNJ not only produces and develops high-quality home use signal booster and high power wireless repeater, but also expands its
business scope to cooperate with signal operators, provide signal coverage solution for large area like residential area, office building, supermarket, underground garage and rural areas.
With the populization of signal repeater, users have more requirements
for the functions of the signal repeater. In 2020, ATNJ developed smarter digital module signal repeater with WIFI connection monitoring function, with which users could control the signal repeater and watch the siganl repeater working situation with their mobile phone. Signal repeaters with WAN connection/Bluetooth connection/USB connection were developed at the same time.
In 2021,5G signal booster was developed and put into Chinese market successfully. In addition, ATNJ starts to upgrade the signal booster
from analog module to digital module, with which the products (micro power signal booster, wireless signal repeater, Indoor Signal Distribution System) could be operated and controlled with WIFI connection, WAN port, USB port and SIM card.
What‘s more, more functions are equipped in our products, like band selective, sub bands, OLED screen display, MGC.With the progress of science and technology of ATNJ, easier use and more functional signal boosters have being developed.
