Product Details
Place of Origin: China
Brand Name: ATNJ
Certification: CE,ROHS，CCC，TUV,BV， ISO
Model Number: JS-DB1800/2100
Document: 1800+2100MHz A032 mobile s...er.pdf
Payment & Shipping Terms
Minimum Order Quantity: 5Pcs
Price: USD+120---140+kit
Packaging Details: Standard neutral packing,52x21x16cm(1 kit), 4kits as 1 carton(53x49x42cm)
Delivery Time: 1-3 work days
Payment Terms: T/T, Western Union,Paypal,Alibaba,Bank transfering.
Supply Ability: 1000+unit+per day.
1800MHz Frequency Range: |
1710-1785MHz / 1805-1880MHz |
2100MHz Frequency Range: |
1920-1980MHz/2110-2170MHz |
Booster Color: |
Gold & Black & White & Customized |
Booster Connect Type: |
N/Female |
Weight: |
4kg |
Packing Size: |
52x21x16cm |
1800MHz Frequency Range: |
1710-1785MHz / 1805-1880MHz |
2100MHz Frequency Range: |
1920-1980MHz/2110-2170MHz |
Booster Color: |
Gold & Black & White & Customized |
Booster Connect Type: |
N/Female |
Weight: |
4kg |
Packing Size: |
52x21x16cm |
ATNJ 1800 2100MHz 2g 3g 4g ALC Dual-Band Signal Extender Amplifier Lte Mobile Network Repeater Cell Phone Signal
OVERVIEW
ATNJ RF repeater with industrial design, combines multi mobile network signals together and improves the mobile voice and data communication, aiming to provide a more cost-effective solution for signal. ATNJ RF repeater is easy to install and maintain, which could help signal providers get fast solution.
A repeater is working as a relay between the BTS and mobiles. It picks up the strongest signal from BTS via the Donor Antenna, linearly amplifies the signal and then re-transmits it via the Indoor Signal Distribution System to the weak/blind coverage area. And the mobile signal is also amplified and re-transmitted to the BTS via the opposite direction.
FEATURES
WHERE TO USE
APPLICATION SCENE
Technical Specification
| SPECIFICATIONS | PARAMETERS | ||
| Frequency Range | LTE 1800 | 1710-1785MHz/1805-1880MHz | |
| UMTS 2100 | 1920-1980MHz/2110-2170MHz | ||
| Band Width | LTE 1800 | 75MHz | |
| UMTS 2100 | 60MHz | ||
| Gain | 68±3 | ||
| Automatic Gain Control | 31dB | ||
| MGC (Step Attenuation) | 20dB@ 1dB/Step | ||
| Output Power | 20±2dBm | ||
| Spurious Emission | 9 kHz -150 kHz/1kHz | ≤-36dBm @1kHz | |
| 150 kHz - 30 MHz/10kHz | ≤-36dBm@10kHz | ||
| 30 MHz - 1 GHz/100kHz | ≤-36dBm@100kHz | ||
| 1 GHz- 12.75 GHz/1MHz | ≤-30dBm@1kHz | ||
| ACPR | Uplink Fully comply with 3GPP 36.106 | ||
| Downlink Fully comply with 3GPP 36.106 | |||
| Unwanted emissions | Fully comply with 3GPP 36.106 | ||
| VSWR | ≤2 | ||
| Ripple | LTE 1800 | ≤5dB | |
| UMTS 2100 | ≤5dB | ||
| Noise Figure | ≤9dB | ||
| Delay | ≤3μs | ||
| I/O Impedance | 50Q | ||
| RF Connector(Customers to Choose) | SMA-Type (Female) | ||
| Operating Temperature | -25°~+55° | ||
| Power Supply | DC 5V2A | ||
| Power consumption | ≤15W | ||
| Environment Conditions | IP43 | ||
| Humidity | ≤90% | ||
| Weight | 0.5kg | ||
| Size | 205×170×38mm | ||
Further detail pls click here for downloading the products specification:
1800+2100MHz A032 mobile signal repeater.pdf
We are manufacturer, and have our own factory.
FAQ:
1. Are you trading company or manufacturer ? Could I use our own logo and label?
We are factory, with trading service. We provide OEM/OEM service.
2. Can I have a sample order? What is your MOQ?
Yes, we welcome sample order to test and check quality. MOQ is 1 for normal products.
3. Is it easy to set up your items?
Yes. We have a user manual and support technical support 24/7.
4. What is your warranty time?
We promise 3-year warranty for all products shipped from us. Man-made sabotage and natural factors are not within the scope of warranty.
5. Please feel free to contact us if any other questions.
