| Brand Name: | ATNJ |
| Model Number: | 5D-FB 10M cable |
| MOQ: | 5Pcs |
| Price: | USD+9--12+kit |
| Packaging Details: | Standard neutral packing10*10*5cm(1pcs), |
| Payment Terms: | T/T, Western Union,Paypal,Alibaba,Bank transfering. |
5D FB Signal Booster Coaxial Cable
ATNJ High Quality Low Loss 5D-FB 10M Coaxial Cable for Mobile Signal Repeater
|
Mechanical Characteristics
|
||
|
1,Impedance
|
50±2Ω(Ohms)
|
|
|
2,Capacitance
|
81±2PF/M
|
|
|
3,Velocity
|
82%
|
|
|
4,Peak Power
|
1.6KW
|
|
|
5,Jacket spark (V.RMS)
|
3000V
|
|
|
6,Inner Conductor Dc resistance
|
≯12ohms/1000m
|
|
|
7,OuterConductor Dc resistance
|
≯31.68ohms/1000m
|
|
|
8,(GHz)cutoff Frequency
|
3G
|
|
|
9,OperatingTemperature ºC
|
-20-70ºC
|
|
|
10,Min Bend Radius
|
75mm
|
|
|
11,Pull strength of the insulation
|
3～6lb/in
|
|
|
12,Sheath of the drawing force
|
3～8lb/in
|
|
|
13,The surface quality of sheath
|
The sheath surface should be smooth and shiny. No visual defects such as bag, slub, fish eye, reticulate, etc.
|
|
|
14,jacket-Marking
|
5D-FB meters
|
|
|
15,Reel Length
|
10M(Customizable length)
|
|
|
16,(>dB)(Screening attenuation)
|
90
|
|
|
17,VSWR
|
30～3000MHZ(Test at both ends of the whole roll≤1.3)
|
|
Further detail pls click here for downloading the products specification:
ATNJ Mobile Signal Repeater.pdf
We are manufacturer, and have our own factory.
FAQ:
Q2: Do you accept OEM order and how long will you shipping after place an order?
A2: We can manufacture according to customer's request and usually we can deliver goods 15-20 days after we receive your deposit.
Q3: What is your payment terms?
A3: We accept Alibaba Trade Assurance, T/T, West Union, Paypal, Bank Account Transfering.
|
|
