ATNJ GSM 900MHz 2G Signal Booster Repeater with 70dB Gain & 300sqm Coverage

Name: ATNJ GSM 900MHz 2G Signal Booster Repeater with 70dB Gain & 300sqm Coverage
Brand: Shenzhen Atnj Communication Technology Co., Ltd.
SKU: AS-G1
Price: 15.00 USD
Availability: InStock

Brand Name:	ATNJ
Model Number:	AS-G1
Price:	$49/pieces 1-29 pieces

Detail Information

Product Description

Detail Information

Place of Origin:

Guangdong, China

Type:

2G Signal Booster

Network:

GPRS, 4g, GSM, 3G, 2G

Frequency:

880-915MHz, 925-960MHz

Gain:

65-70dB

AGC:

Max. Output Power:

15~27dBM

Coverage:

300sqm

Weight:

Approx 1.3kg

Size:

165*115*35mm

Application:

Home,office, Apartments,basement,shopping Mall, Parking ...ect.

Material:

ABS Plastic

Warranty:

3 Years

Highlight:

GSM 900MHz signal booster

2G signal repeater 70dB gain

300sqm coverage mobile booster

Product Description

ATNJ GSM 900MHz 2G Signal Booster Repeater with 70dB Gain & 300sqm Coverage

Product Overview

Attribute	Value
Type	2G signal booster
Network	GPRS, 4G, GSM, 3G, 2G
Frequency	880-915MHz, 925-960MHz
Gain	65-70dB
AGC	30
Max. Output power	15~27dBM
Coverage	300sqm
Weight	Approx 1.3kg
Size	16511535mm
Application	Home, office, apartments, basement, shopping mall, parking, etc.
Material	ABS Plastic
Warranty	3 Years

Technical Specifications

Specifications	Parameters
Frequency Range (Customers to Choose)
Uplink	890-915MHz
Downlink	935-960MHz
Frequency Bandwidth (3dB Bandwidth)	75MHz & 60MHz
Gain	70dB
Automatic gain control (Step Attenuation)	31dB @ 1dB/ Step
Auto Gain Control	20dB Min.
Output Power(Customers to Choose)	20dBm
Spurious Emission	≤ -15dBm/30kHz 9kHz~1GHz: ≤ -36dBm/30kHz 1GHz~12.75GHz: ≤ -30dBm/30kHz
Inter-Modulation Attenuation ACPR	≤ -40dBc / 30kHz (measured under rated output power)
In-band Ripple	≤ 3dB
VSWR	<=2
I/O Impedance	50 Ω
Noise Figure	≤ 5dB
System Delay	≤ 5μs
RF Connector(Customers to Choose)	SMA (Female)
Operating Temperature	Operation: -10°C ~ +55°C / Storage: -20°C ~ +60°C
Power Supply	AC 110~220V±20%, 50/60Hz(AC 220V/ DC5V/2A power adapter)
Dimensions	16513040 (mm)
Weight	≤0.8 kg(Net)
Alarm Monitoring System	Alarm for uplink self-oscillation
Indication LED	Power supply
