33dBm Outdoor Selective Band Signal Booster LTE 900/1800/2100MHz
| 900MHz Frequency Range: | 890–910MHz/ 935–955MHz | 1800MHz Frequency Range: | 1745–1765MHz/1840–1860MHz |
| 2100MHz Frequency Range: | 1920–1935/2110–2125MHz; 1935-1950/2125-2140MHz | Bandwidth: | Wide Range |
| Local Control: | WIFI/ Type-C Port, Bandwidth Adjustment Could Be Done By Type-C Only | Remote Control: | Cloud WEB Platform By SIM Card |
| RF Connector(Customers to Choose): | N -Type (Female) | ||
| High Light: | 33dBm Outdoor Selective band Signal Booster,4G Outdoor Selective Band Signal Booster,Wideband Outdoor Selective Band Signal Booster |
||
33dBm Outdoor Selective band Signal Booster LTE 900/1800/2100MHz 4G Wideband Signal Amplifier for Rural Area
Product Introduction:
The digital Repeater is designed to provide a more cost-effective
solution than adding a new Base Transceiver Station (BTS) to
improve signal coverage and communication quality in single
system. And its easy installation and maintenance can help carrier
get fast return.
It is working as a relay between the BTS and mobiles.
It receives the low-power signal from BTS via the Donor Antenna,
linearly amplifies the signal and then retransmits it via the
Coverage Antenna to the weak/blind coverage area. And the
mobile signal is also amplified and retransmitted to the BTS via the opposite direction.
④ Automatic adjust the system gain to avoid the repeater self-excitation .
⑤ Initiative reminding when the device was damaged .
⑥ Supports from 0.2 to 20MHz bandwidth adjusted(Customized) ,Supports 5G bandwidth,40MHz,50MHz,60MHz,70MHz,80MHz,90MHz,100MHz(Frequency Bandwidth Customized) .
Technical Specifications:
|
SPECIFICATIONS
|
PARAMETERS
|
||
|
Frequency Range
|
900MHz
|
UL890–910MHz, DL935–955MHz
|
|
|
1800MHz
|
UL1745–1765MHz, DL1840–1860MHz
|
||
| 2100MHz | UL1920–1935MHz, DL2110–2125MHz | ||
|
2100MHz
|
UL1935–1950MHz, DL2125–2140MHz
|
||
|
Bandwidth
|
900MHz
|
supports 1 subband from 0.2 to 20 MHz adjusted
|
|
|
1800MHz
|
supports 1 subband from 0.2 to 20 MHz adjusted
|
||
|
2100MHz
|
supports 2 subband from 0.2 to 15 MHz adjusted
|
||
| RF Carriers ARFCN Filtering | Digital | ||
|
Gain
|
UL: 75±3 dB DL: 80±3dB
|
||
|
Output Power
|
UL: 20±2dBm DL: 33±2dBm
|
||
|
Automatic Gain Control
|
30dB/1dB
|
||
|
Minimum Input power
|
≥ -90dBm
|
||
| Gain Flatness / PB Ripple | ＜ 4dB | ||
| Automatic Level Control | ≥ 25dB | ||
|
Unwanted emissions
|
Fully comply with 3GPP 36.106
|
||
|
EVM
|
≤8
|
||
|
VSWR
|
≤1.8
|
||
|
Noise Figure
|
≤8dB
|
||
|
Delay
|
≤10μs
|
||
|
RF Connector(Customers to Choose)
|
N -Type (Female)
|
||
|
Storage temperature range
|
-40°C to +85°C
|
||
|
Operating Temperature
|
-25°~+55°
|
||
|
Power Supply
|
195-265 VAC
|
||
|
Power consumption
|
≤100W
|
||
| Barometric pressure | 55 kPa -106 kPa | ||
|
Environment Conditions
|
IP65
|
||
|
Relative humidity
|
5% - 95%
|
||
|
Weight
|
≤20kg
|
||
|
Size
|
596 x 400 x 203.5 mm
|
||
Product Description
1.
Q: Why choose us for cooperation?
A: We have the professional engineer to develop and make them suit for all over the world.we also will deal with all the problem when you have problem and reply to you at any time.
2.
Q: Does the signal booster work have radiation or not ?
A: Yes,but just little ,it also can reduce the radiation when you calling ,because it will have more radiation if no signal when you dialing on your phone.So don’t worry and use in house ,it is better for you than not use when no signal in house.
3.
Q: Can I install a signal repeater myself?
A: Absolutely. There is no technical expertise required to install your mobile signal repeater kit. Each kit contains everything needed to improve the mobile coverage in your home/office and includes instructions that will guide you through the simple steps necessary to install your repeater.
4.
Q: Can this mobile signal repeater create a signal where there is no cell signal before?
A: The mobile signal repeater cannot produce a signal, only amplify a weak one.
-
AIt works great, the frequency can be adjusted to Vodafone correctly,and LTE speed goes fast.
-
MShipment arranged in time,and the repeater working well.
-
HAll ATNJ products are very well made at a reasonable price. Our clients are delighted with their products and their service and attention is phenomenal. Really recommend them
